Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-10S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-10S Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ63X100-10S
- Type: Dual-axis adjustable stroke cylinder (square body)
- Bore size: 63mm
- Stroke: 100mm (adjustable via external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Front flange & rear foot mounting holes (M6×4)
- Port size: G1/8 (ISO standard)
- Rod diameter: 20mm (chrome-plated steel)
- Body material: Anodized aluminum alloy (black finish)
- Seal material: NBR/PU (oil & dust resistant)
- Protection rating: IP54 (standard wiper seal)
- Stroke adjustment range: 0-100mm (±0.5mm repeatability)
- Weight: 2.85kg (without accessories)
- Dimensions: 270mm(L) × 85mm(W) × 85mm(H) (at full extension)
High-precision dual-rod cylinder with integrated stroke adjustment mechanism, featuring symmetrical force distribution for stable linear motion. Includes dual shock absorbers and anti-rotation guide rods (Ø16mm hardened steel) for precise positioning. Compatible with magnetic sensors (sensor slot: 5.5mm width).
- Precision alignment in semiconductor handling robots
- Vertical lifting mechanisms for CNC tool changers
- Position-controlled clamping fixtures in auto parts assembly
- Material transfer systems requiring anti-torsion stability
- Packaging machine product height adjustment stations
Installation notes:
Lubricate rods with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install lock nuts on adjustment bolts.
Maintain 0.5mm minimum clearance between stoppers during adjustment.
- Air quality: ISO 8573-1 class 3.4.2 (max 5μm particles)
- Relative humidity: Below 80% (non-condensing)
- Vibration resistance: ≤4.9m/s² at 10-60Hz
| Property | Property Value |
|---|---|
| sku | SIJ63X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
