Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-10TC
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-10TC Double-Axis Adjustable Cylinder Specifications
- Model: SIJ63X100-10TC
- Type: Double-axis adjustable cylinder with dual guide rods
- Bore size: 63 mm
- Stroke: 100 mm (±5mm adjustable)
- Rod diameter: 16 mm (both rods)
- Mounting style: Front flange with through-hole installation
- Operating pressure: 0.1–1.0 MPa
- Cushion type: Adjustable rubber buffer + external shock absorber
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Port size: G1/8 (ISO228 standard)
- Weight: 2.8 kg (with standard accessories)
- Dimensions: 206mm(L) × 80mm(W) × 63mm(H)
- Rod material: Chrome-plated carbon steel (S45C)
- Protection rating: IP54 (standard dust/moisture resistance)
- Lubrication: Pre-lubricated (relubrication interval: 3,000 km)
High-precision dual-rod cylinder designed for applications requiring exceptional lateral stability and positional accuracy. Features synchronized dual-axis movement with adjustable stroke limiter (hex wrench adjustable). The hardened guide rods and double-sealed piston ensure smooth operation in high side-load scenarios.
- Precision press-fit operations in electronics assembly
- Vertical lifting mechanisms for automated packaging lines
- Fixture positioning in CNC machining centers
- Material transfer gates in automotive production
- 3D printer bed stabilization systems
Installation tip:
Align guide rods within 0.2mm parallel tolerance during mounting.
Use locknuts (included) for stroke adjustment. For continuous
operation >0.7MPa, install auxiliary cooling for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SIJ63X100-10TC |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
