Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-50SH
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-50SH Double Rod Adjustable Cylinder Specifications
- Model: SIJ63X100-50SH
- Type: Double rod compact cylinder with stroke adjustment
- Bore size: 63 mm
- Stroke: 100 mm (adjustable)
- Rod diameter: 16 mm (both rods)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable stroke mechanism
- Mounting type: Standard foot mounting (MF1) with dual axis fixing
- Port size: M5x0.8 (G1/8 adaptor optional)
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 2.5 kg ±3%
- Dimensions: 200mm(L) × 78mm(W) × 63mm(H)
- Protection rating: IP54 (standard), IP67 (optional wiper kit)
- Certification: ISO 6432, TUV, RoHS compliant
High-precision dual-axis cylinder featuring independent stroke adjustment through rotating end-lock nuts (50mm max adjustment range). The symmetrical dual-rod design ensures exceptional lateral load capacity and position stability. Pre-lubricated with anti-corrosion treatment for maintenance-free operation in harsh environments. Includes magnetic piston for sensor compatibility.
- Precision positioning in robotic arm tool changers
- Simultaneous clamping mechanisms in CNC fixtures
- Vertical lifting platforms in packaging lines
- Material handling systems requiring bidirectional force
- Semiconductor wafer transfer equipment
- Pharmaceutical tablet pressing machines
Installation tips:
Use locknuts on both adjustment ends after setting required stroke.
Maintain 0.5-1mm clearance between rods and adjacent components.
For vertical installations, add external guide mechanisms for heavy loads.
| Property | Property Value |
|---|---|
| sku | SIJ63X100-50SH |
| Adjustable Stroke | <50mm> |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
