Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-10S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X1000-10S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ63X1000-10S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Piston rod diameter: Ø20mm (both ends)
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Front flange/Foot mount (optional accessories)
- Seal material: NBR + Polyurethane
- Ambient temperature: -10℃ to 70℃
- Port size: G1/2
- Weight: 15.8kg (without accessories)
- Dimensions: 1135mm(L) × 86mm(W) × 86mm(H)
- Rod end thread: M10×1.25 (both rods)
- Protection class: IP40 (standard)
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision dual rod cylinder with stroke adjustment mechanism, featuring synchronized dual piston rods for enhanced rigidity and positional accuracy. The chrome-plated rods and aluminum alloy body provide corrosion resistance, while the integrated guide grooves allow direct sensor mounting. Includes magnetic piston for position detection compatibility.
- Precision alignment systems in semiconductor manufacturing
- Long-stroke material transfer in automotive assembly lines
- Simultaneous clamping mechanisms in CNC fixtures
- Vertical lifting platforms with guided motion
- Packaging line product positioning gates
Installation note:
Ensure proper alignment of dual rods using alignment jigs during installation.
For full-stroke operation, maintain 50mm clearance at both ends.
Use locknuts (included) for stroke adjustment fixation.
Recommended air filtration: 5μm with auto-drain.
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
