Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-20S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63 Dual-Axis Adjustable Cylinder SIJ63X1000-20S Specifications
- Model: SIJ63X1000-20S
- Type: Dual-axis adjustable stroke cylinder with guide rods
- Bore size: Ø63mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Rod thread: M20×1.5 (ISO standard)
- Mounting type: Basic type (no built-in mounting)
- Operating temperature: -10℃ to 80℃
- Weight: 12.8kg ±2% (without accessories)
- Dimensions: 1400mm(L) × 120mm(W) × 98mm(H)
- Rod material: Chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: Polyurethane (NBR optional)
- Protection rating: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
High-precision dual-rod cylinder designed for heavy-duty linear motion requiring exceptional lateral load capacity. Features twin guide rods (Ø20mm) with adjustable stroke mechanism for precise positioning. The 63mm bore provides 314N thrust at 0.5MPa. Integrated mounting slots allow flexible installation configurations.
- Automated material handling systems
- Precision glass cutting machinery
- Electronics assembly line positioning
- Automotive welding fixture actuators
- Packaging machine vertical lift mechanisms
Installation note:
Maintain parallel alignment within 0.2mm/m during installation.
For full-stroke applications, allow 50mm clearance at both ends.
Lubricate guide rods weekly in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
