Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-30S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63 Dual-Axis Adjustable Cylinder SIJ63X1000-30S Specifications
- Model: SIJ63X1000-30S
- Type: Double-rod adjustable stroke cylinder
- Bore size: 63 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Piston rod diameter: 20 mm (dual rods)
- Mounting style: Front flange/Foot mount (optional accessories)
- Cushion type: Adjustable pneumatic cushion
- Seal material: NBR (standard)/PU (optional)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard)/G1/8 (optional)
- Weight: 14.8 kg ±2% (without accessories)
- Dimensions: 1250mm(L) × 125mm(W) × 85mm(H) (full extension)
- Rod end thread: M10x1.25 (both ends)
- Protection rating: IP40 (standard)/IP65 (wipers installed)
High-rigidity dual-rod cylinder with precision ground rods and adjustable stroke mechanism. Features corrosion-resistant aluminum alloy construction with chrome-plated piston rods. The dual-axis design provides enhanced lateral load capacity and precise linear motion. Includes magnetic piston for sensor compatibility and adjustable cushioning for smooth end-of-stroke deceleration.
- Long-stroke press machines
- Automated material transfer systems
- Packaging line positioning devices
- Textile machinery tension control
- Automotive assembly fixtures
- 3D printing gantry systems
Installation note:
Ensure proper alignment of dual rods using alignment jigs during mounting.
Maintain 0.5-1mm clearance between rods and guides. Lubricate with ISO VG32
hydraulic oil before initial operation. Maximum side load: 180N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
