Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-40S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X1000-40S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ63X1000-40S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Max thrust: 1,550N @0.7MPa
- Piston speed: 50-1000mm/s
- Cushioning: Adjustable hydraulic shock absorber
- Mounting style: Fixed base with dual-axis support
- Port size: G1/8 (Rc1/8 optional)
- Material: Aluminum alloy body, chromium-plated piston rod
- Seal type: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 12.8kg ±3%
- Dimensions: 1,450mm(L) × 128mm(W) × 128mm(H)
- Stroke adjustment: ±1mm precision via mechanical stoppers
- Protection rating: IP54 (standard), IP67 (optional)
High-precision dual-axis cylinder with through-rod design for synchronized motion control. Features wear-resistant guide mechanisms with adjustable stroke limiters on both ends, ideal for heavy-load applications requiring parallel alignment. Includes anti-rotation pins for enhanced stability during long-stroke operations.
- Automated palletizing systems
- Precision glass cutting machinery
- Battery module assembly lines
- Sheet metal bending equipment
- Solar panel handling robots
Installation note:
Requires horizontal mounting with alignment tolerance ≤0.1mm/m.
Lubricate guide shafts weekly with ISO VG32 hydraulic oil.
Maximum side load capacity: 300N (axial), 150N (radial).
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
