Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63 Dual-Axis Adjustable Cylinder SIJ63X1000-50S Specifications
- Model: SIJ63X1000-50S
- Type: Dual-axis adjustable guide cylinder
- Bore size: 63mm
- Stroke: 1000mm
- Rod type: Double rod (Dual axis)
- Adjustment range: ±5° (Angular adjustment)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Elastic buffer
- Mounting style: Side flange (MF1)
- Port size: G1/8
- Material: Aluminum alloy cylinder tube, hard chrome-plated piston rod
- End cover material: Die-cast aluminum
- Weight: Approximately 8.5kg (with standard components)
- Dimensions: 1130mm(L) × 125mm(W) × 135mm(H) (Stroke length included)
- Rod diameter: 20mm (per axis)
- Maximum lateral load: 150N
- Protection class: IP54
High-precision dual-axis cylinder with unique angular adjustment mechanism, featuring synchronized movement control through parallel guide rods. The 50S variant includes reinforced mounting brackets and wear-resistant guide bushings. Designed for heavy-duty applications requiring precise linear motion with adjustable angular alignment tolerance.
- Precision alignment in automated assembly lines
- Material handling systems with dual-axis positioning
- Automotive welding fixture adjustments
- Packaging machinery requiring synchronized lifting & pressing
- Glass panel handling with angular compensation
Installation note:
Requires periodic lubrication (VG32 hydraulic oil recommended).
Maintain 0.5mm minimum clearance between guide rods during alignment.
Maximum angular adjustment should not exceed 5° during operation.
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
