Airtac SU32~50 Standard Cylinder SU32X1050
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1050 Standard Cylinder Specifications
- Model: SU32X1050 (SU32~50 series)
- Bore size: 32 mm
- Stroke: 1050 mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: Rc1/8 (G1/8 optional)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodization
- Seal material: NBR/PU (temperature-resistant variant available)
- Ambient temperature: -20℃ to 80℃
- Mounting types: Basic type (MF1), front flange (MP4), rear flange (MP5)
- Weight: 3.8 kg (with 1050mm stroke)
- Dimensions: 1140mm(L) × 52mm(W) × 52mm(H) (full extended length)
- Protection rating: IP54 (standard), IP67 optional
- Piston speed: 50–800 mm/s
A heavy-duty long-stroke pneumatic cylinder featuring precision honed tubing and dual anti-rotation guides. Optimized for high-moment load applications with built-in magnet for position sensing. Corrosion-resistant construction enables operation in humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automated palletizing systems
- Plastic injection molding ejectors
- Automotive assembly line positioning
- Textile machinery tension control
- Solar panel cleaning robots
Installation note:
For strokes over 500mm, use intermediate support brackets to prevent rod deflection.
Lubricate with ISO VG32 hydraulic oil if operating below 1 m/s. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SU32X1050 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 1050mm |
