Airtac SU32~50 Standard Cylinder SU32X1050SN
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1050SN Standard Cylinder Specifications
- Model Series: SU32~50 series
- Bore Size: Ø32mm
- Stroke Length: 1050mm (customizable 50-1000mm)
- Operating Pressure: 0.05-1.0 MPa
- Cushion Type: Adjustable air cushion (both ends)
- Mounting Style: Basic type (MF1) with standard ISO/VDS mounting
- Port Size: Rc1/4 (NPT1/4 optional)
- Piston Speed: 50-750 mm/s (optimal at 200-500 mm/s)
- Ambient Temperature: -20℃ to 80℃
- Material:
- Cylinder Tube: Aluminum alloy (hard anodized)
- Piston Rod: Chrome-plated steel (S45C)
- End Caps: Extruded aluminum
- Seal Material: NBR (nitrile rubber) standard
- Weight: ~5.8kg (excluding accessories)
- Dimensions:
- Extended Length: 1350mm (stroke + 300mm base length)
- Body Width: 52mm
- Height with Mounts: 78mm
- Protection Class: IP54 (standard wipers)
High-precision long-stroke pneumatic cylinder featuring wear-resistant construction and precision honed tube. The double-acting design with magnetic piston enables position feedback when used with sensors. Optimized for heavy-duty cycles with 3,000km+ service life under proper lubrication (ISO VG32 recommended). Includes anti-rotation guide for moment load applications.
- Automated material handling systems
- Plastic injection molding ejectors
- Automotive assembly line positioning
- Paper processing equipment actuators
- Packaging machine vertical lifts
Installation note:
For long-stroke applications exceeding 800mm, use horizontal mounting with intermediate supports every 600mm. Maintain 0.5-1mm/m alignment tolerance. Lubricate through air supply (ISO VG32) or use built-in lubricator.
Critical parameters:
Max side load 85N, buckling load 1,200N at full extension. For vertical mounting, use counterbalance valves. Avoid rapid direction changes above 80% max speed.
| Property | Property Value |
|---|---|
| sku | SU32X1050SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 1050mm |
