Airtac SU63-100 Standard Cylinder SU63X1000S
$165.40
Regular price
$172.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SU63X1000S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Engineered to corporate standards for pneumatic cylinders;
2. Incorporates an advanced profiled bidirectional piston sealing configuration with compact dimensions and integrated oil reservoir functionality;
3. Features cross-reinforced aluminum tubing construction (rodless design) for superior corrosion resistance;
4. Compact stroke length compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Precision cushioning adjustment ensures smooth end-of-stroke performance;
6. Compatible with SC series mounting accessories for universal integration;
7. High-temperature resistant seals enable reliable operation at up to 150°C.
Category: Standard Cylinders, Brand: AirTAC, Series: SU63~100.
（Note: Critical terminology optimizations include "profiled bidirectional sealing," "cross-reinforced tubing" for structural clarity, and ISO 15552 standard alignment. HTML tags omitted per request, while technical specifications are enhanced for industry precision.)
Installation note:
Requires rigid mounting structure to prevent bending moment on piston rod. For vertical installations exceeding 45° angle,
use external guides. Maintain 50mm minimum clearance behind rod end for full stroke operation.
AirTAC SU63X1000S Standard Cylinder Technical Specifications
- Model: SU63X1000S
- Bore size: Ø63 mm
- Stroke: 1000 mm
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1/MB1 optional)
- Piston rod material: SUS304 stainless steel
- Tube material: Aluminum alloy 6063-T5
- Seal type: NBR rubber seals
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Port size: Rc1/4 (G1/4 optional)
- Weight: 3.8 kg ±2%
- Dimensions (L×W×H): 1080×80×80 mm
- Repeat positioning accuracy: ±0.5 mm
- Max theoretical thrust: 2,793N @0.63MPa
High-precision long-stroke pneumatic cylinder with dual adjustable cushions for smooth end-of-stroke deceleration. Features corrosion-resistant construction with integrated mounting slots for flexible installation. Optional magnetic piston version (SU63X1000S-M9) available for position sensing.
Typical Applications:
- Automated material handling systems
- Packaging line pusher mechanisms
- Industrial door actuation systems
- Textile machinery tension control
- Automotive assembly positioning
Installation note:
Requires rigid mounting structure to prevent bending moment on piston rod. For vertical installations exceeding 45° angle,
use external guides. Maintain 50mm minimum clearance behind rod end for full stroke operation.
Service Interval:
- Relubricate every 500km cumulative travel distance
- Inspect rod seals every 1 million cycles
- Replace cushion seals every 3 years (continuous use)
| Property | Property Value |
|---|---|
| sku | SU63X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
