Airtac TCM Triple Axis Cylinder TCM50X75-S
$170.82
Regular price
$178.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM50X75-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation guidelines:
Mount on rigid flat surface (flatness ≤0.1mm/m). Use regulated lubricated air (ISO 8573-1 class 4.4.3).
For vertical installations, add mechanical brake on Z-axis. Lubricate guide rails with ISO VG32 hydraulic oil
during initial setup.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM Series 3-Axis Cylinder TCM50X75-S Technical Specifications
- Model: TCM50X75-S
- Type: Triple-axis compact guided cylinder (X/Y/Z motion)
- Bore diameter: 50mm (ISO 6432 standard)
- Stroke: 75mm (adjustable stroke version available as TCM50X75-SA)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Temperature range: -10℃ to 80℃ (non-freezing environment)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Standard flange mounting with 4×M6 threaded holes
- Port size: G1/8 (NPT1/8 optional)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated carbon steel (STS303 optional)
- Seals: NBR (HNBR/Viton available for high-temp versions)
- Weight: 5.8kg (including mounting hardware)
- Dimensions:
- Total length: 312mm (including rod end)
- Body width: 98mm (guide block dimension)
- Height: 112mm (from base to top guide rail)
- Position detection: Magnetizable piston (sensor slots on two axes)
- Protection class: IP54 (standard), IP67 (optional with wiper seals)
Precision triple-axis pneumatic actuator combining three independent cylinders in a space-saving orthogonal configuration. Features dual linear guides with adjustable preload for minimal play (±0.05mm repeatability). Anti-rotation design maintains positional accuracy under side loads up to 120N. Compatible with AirTAC MHL2/MHW2 series magnetic sensors (sold separately).
Typical Applications:
- Multi-axis positioning in CNC tool changers
- PCB handling robots in electronics assembly
- Automated optical inspection (AOI) equipment
- Precision alignment stages for semiconductor manufacturing
- Packaging machine product orientation systems
Installation guidelines:
Mount on rigid flat surface (flatness ≤0.1mm/m). Use regulated lubricated air (ISO 8573-1 class 4.4.3).
For vertical installations, add mechanical brake on Z-axis. Lubricate guide rails with ISO VG32 hydraulic oil
during initial setup.
| Property | Property Value |
|---|---|
| sku | TCM50X75-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <50mm> |
| Stroke | 75mm |
| Bearing Code | Bronze Bushing |
