Airtac TCM Triple Axis Cylinder TCM63X40-S
$169.27
Regular price
$176.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM63X40-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Maintenance protocol:
Lubricate every 500km stroke travel using ISO VG32 turbine oil.
Avoid side-load exceeding 150N. For vertical mounting,
use counterbalance valve (AV-02 accessory recommended).
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM Series 3-Axis Cylinder TCM63X40-S Technical Details
- Model: TCM63X40-S
- Type: Triple-axis compact guided cylinder (ISO 6432 compliant)
- Bore size: Ø63mm
- Stroke: 40mm (customizable 10-300mm)
- Operating pressure: 0.1-0.8 MPa
- Piston speed: 50-800 mm/s
- Cushioning: Adjustable hydraulic shock absorber
- Mounting style: Front flange MF12×1.25 with reinforced base
- Rod material: Hard chrome-plated carbon steel (HRC 45-50)
- Seal type: HNBR/NBR hybrid seals with wear indicator
- Ambient temperature: -20℃ to 80℃
- Weight: 2.65 kg (without accessories)
- Dimensions: 208mm(L) × 82mm(W) × 82mm(H) (full extension)
- Port size: M5x0.8 dual auto-switch ports
- Position detection: Built-in magnet for sensor mounting
- Repeat accuracy: ±0.05mm
Precision triple-axis pneumatic actuator with integrated guide rails, designed for multi-directional force transmission in space-constrained environments. Features anti-rotation mechanism (patented T-slot design) and dust-resistant wiper seals. Requires ISO 8573-1:2010 Class 3 compressed air with 1μm filtration.
Industrial Applications:
- PCB component insertion machines
- Automotive welding fixture positioning
- Pharmaceutical blister packaging systems
- Robotic end-effector force control
- Optical lens polishing equipment
Maintenance protocol:
Lubricate every 500km stroke travel using ISO VG32 turbine oil.
Avoid side-load exceeding 150N. For vertical mounting,
use counterbalance valve (AV-02 accessory recommended).
| Property | Property Value |
|---|---|
| sku | TCM63X40-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 63mm |
| Stroke | <40mm> |
| Bearing Code | Bronze Bushing |
