Airtac TCM Triple Axis Cylinder TCM63X50-S
$174.44
Regular price
$181.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM63X50-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation note:
Mount on machined surface with flatness ≤0.1mm/m. Use M6x12 mounting screws (ISO 4762)
at 0.5-0.6Nm torque. Align guide rails within 0.05mm parallel tolerance during installation.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM63X50-S Triple Axis Cylinder Specifications
- Model: TCM63X50-S
- Type: Compact triple-axis guided cylinder (X/Y/Z motion)
- Bore size: Ø63mm
- Stroke: 50mm (standard), customizable up to 300mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Body material: Anodized aluminum alloy (AL6063)
- Seal material: NBR (nitrile rubber) with wear-resistant rings
- Port size: 1/4" NPT (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Mounting style: Side-mount with precision linear guides
- Repeat accuracy: ±0.05mm
- Max thrust: 1,250N @0.6MPa
- Weight: 2.65kg (without accessories)
- Dimensions: 180mm(L) × 63mm(W) × 63mm(H) (stroke 50mm)
- Protection rating: IP54 (standard), IP67 optional
High-precision multi-axis cylinder with integrated linear guides and dual piston rods. Features anti-rotation mechanism for stable Z-axis movement and optional magnetic sensor slots (M9x1 mounting). Designed for complex positioning tasks requiring rigid guidance and minimal deflection. Requires ISO 8573-1 class 3 lubricated or non-lubricated air.
Typical Applications:
- Automated robotic tool changers
- Precision assembly of electronic components
- CNC machine tool clamping systems
- 3-axis material handling robots
- Optical lens positioning stages
Installation note:
Mount on machined surface with flatness ≤0.1mm/m. Use M6x12 mounting screws (ISO 4762)
at 0.5-0.6Nm torque. Align guide rails within 0.05mm parallel tolerance during installation.
| Property | Property Value |
|---|---|
| sku | TCM63X50-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 63mm |
| Stroke | <50mm> |
| Bearing Code | Bronze Bushing |
