Airtac TCM Triple Axis Cylinder TCM63X70-S
$198.22
Regular price
$205.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM63X70-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation note:
Use precision alignment jigs during mounting. Lubricate with ISO VG32 hydraulic oil
before initial operation. Maintain 0.5mm minimum clearance between adjacent cylinders
for heat dissipation. Avoid side-load exceeding 15% of maximum thrust capacity.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM Series 3-Axis Cylinder TCM63X70-S Technical Specifications
- Model: TCM63X70-S
- Type: Triple-axis guided cylinder (X/Y/Z linear motion)
- Bore size: Ø63mm
- Stroke: 70mm (customizable 25-500mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting options: Front flange (TF1), rear flange (TF2), side mount
- Port size: M5x0.8 (standard), G1/8 optional
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (nitrile) with wear-resistant ring
- Temperature range: -20℃ to +80℃
- Weight: 2.5kg (excluding accessories)
- Dimensions: 150mm(L) × 98mm(W) × 98mm(H) (at mid-stroke)
- Repeat accuracy: ±0.05mm
- Max lateral load: 30N
- Protection rating: IP40 (IP67 with optional wiper)
Precision triple-axis pneumatic cylinder featuring integrated linear guides and dual piston design. The TCM63X70-S delivers synchronized multi-directional movement with anti-rotation stability, ideal for complex positioning tasks. Enhanced with double-sealed bearings and corrosion-resistant coating for industrial environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
Typical Applications:
- Automated pick-and-place systems with angular correction
- Precision alignment in semiconductor handling equipment
- Multi-axis positioning in CNC fixture changers
- 3D material handling in automotive assembly lines
- Packaging machinery with Z-axis pressing functions
Installation note:
Use precision alignment jigs during mounting. Lubricate with ISO VG32 hydraulic oil
before initial operation. Maintain 0.5mm minimum clearance between adjacent cylinders
for heat dissipation. Avoid side-load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | TCM63X70-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 63mm |
| Stroke | 70mm |
| Bearing Code | Bronze Bushing |
