Airtac 4V Coil Terminal 4V210-016-9A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-9A Coil Terminal Specifications
- Model: 4V210-016-9A
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.9 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 220g ±5g (excluding accessories)
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Seal material: Heat-resistant NBR (optional FKM available)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Power consumption: 2.8W (DC24V), 3.5VA (AC220V)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement 7.5mm)
High-flow solenoid valve with dual electrical connectors for bidirectional control, featuring dust-tight coil protection and rapid cycling capability. The zinc-nickel plated brass body provides enhanced corrosion resistance. Includes manual override and position-indication LED (optional). Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality.
- Automated production line actuators
- Textile machinery cylinder control
- Plastic injection molding ejectors
- Food processing pneumatic systems (food-grade grease option)
- Semiconductor handling equipment
Installation guidelines:
Mount in vibration-free environments using M4 mounting screws (max torque 1.2N·m).
Maintain 20mm clearance from heat sources. Lubricate seals with ISO VG32 oil
if operating below -5℃. Replace coalescing filters every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | 4V210-016-9A |
