Airtac 4V100 Solenoid Valve 4V11006A-W
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006A-W Technical Specifications
- Model Number: 4V11006A-W
- Valve Type: 5-port/2-position (5/2-way) direct acting with spring return
- Port Thread: PT1/4 (G1/4 equivalent) with ISO 228-1 standard
- Operating Pressure Range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation: Class F (155℃)
- Flow Capacity: 1,200 l/min (Cv=1.8) at 0.5 MPa
- Seal Material: Heat-resistant NBR (Nitrile) -70℃ to +120℃
- Body Material: Die-cast aluminum alloy with hard anodized finish
- Response Time: ≤15ms (energized), ≤20ms (de-energized)
- Protection Class: IP67 (dust-tight and protected against temporary immersion)
- Weight: 530g ±5% (including coil and accessories)
- Dimensions: 120mm(L) × 50mm(W) × 45mm(H) (manual override adds 12mm to height)
- Porting Pattern: ISO 5599-1 compliant (standardized mounting interface)
- Lubrication: Pre-lubricated (maintenance-free for 20 million cycles)
High-flow 5/2-way pneumatic valve engineered for industrial automation systems requiring bidirectional cylinder control. Features zero-pressure start capability and surge protection circuitry in the coil. The manual override allows mechanical actuation during system commissioning or power failures. Requires 5μm filtration with automatic drain.
- Pneumatic press clamping/unclamping mechanisms
- Rotary actuator control in packaging lines
- Material handling systems with tandem cylinders
- Plastic injection molding machine ejectors
- Automated assembly line tool changers
Maintenance Protocol:
For optimal performance, perform air leakage test every 2,000 operating hours using soap bubble method.
Coil replacement requires torque control (0.8-1.2 N·m) to prevent body deformation.
Critical Notice:
Not compatible with phosphate ester-based lubricants. Use ISO VG32 turbine oil if supplementary
lubrication is required. Avoid rapid pressure fluctuations exceeding 0.5 MPa/sec.
| Property | Property Value |
|---|---|
| sku | 4V11006A-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
