Airtac 4V100 Solenoid Valve 4V11006AI-AM
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006AI-AM Technical Details
- Model Code: 4V11006AI-AM
- Valve Type: 4V1-series 5/2-way single solenoid (monostable)
- Port Thread: G1/8 (ISO228/1 standard)
- Effective Section Area: 18mm²
- Operating Pressure Range: 0.1-0.9 MPa
- Voltage Variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation Class: Class F (155℃)
- Power Consumption: 2.2W (DC), 3.5VA (AC)
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient Temperature: -5℃ to 60℃ (no freeze)
- Fluid Temperature: 0-60℃
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Body Material: Die-cast aluminum alloy (anodized surface)
- Protection Rating: IP67 (dustproof & temporary immersion)
- Weight: 280g ±5g (with coil)
- Dimensions: 58mm(L) × 35mm(W) × 72mm(H) (excluding connectors)
- Port Positions: P (pressure), A/B (actuator ports), R/S (exhausts)
- Manual Override: Optional push-button type (front-mounted)
- Mounting Options: Direct piping or sub-base mounting (ISO 5599-1)
High-flow 5/2-way pneumatic valve optimized for mid-pressure industrial automation systems. Features dual-pressure capability for cylinder control and quick exhaust function. The low-hysteresis design ensures precise directional switching in repetitive operations. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particulate, -20℃ pressure dew point).
- Pneumatic cylinder sequencing in assembly lines
- Clamping/unclamping mechanisms in CNC machinery
- Material handling systems with dual-acting cylinders
- Textile machinery thread control devices
- Automated welding equipment gas flow switching
Installation Guidelines:
Mount with vibration-damping brackets in high-frequency operation environments.
Maintain ≥50mm clearance below exhaust ports for unimpeded airflow.
Use copper-free anti-seize compound on threaded ports (max 15Nm torque).
| Property | Property Value |
|---|---|
| sku | 4V11006AI-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
