Airtac 4V100 Solenoid Valve 4V11006BI-AM-W
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006BI-AM-W Technical Details
- Model Code: 4V11006BI-AM-W
- Valve Type: 5/2-way (double solenoid with spring return)
- Port Thread: PT1/4 (G1/4 optional)
- Operating Pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage Variations: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Manual Override: Built-in emergency manual operation
- Flow Capacity: 850 l/min (Cv=1.3 at 0.5 MPa)
- Response Time: ≤15ms (at rated voltage)
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient Temperature: -5℃ to 80℃ (no freeze)
- Protection Class: IP67 (dust-tight, protected against temporary immersion)
- Weight: 480g ±3% (with coil)
- Dimensions: 56mm(W) × 54mm(H) × 120mm(L)
High-flow bistable solenoid valve with dual electrical/pneumatic control capabilities. Features brass main body with anodized aluminum solenoid housing for corrosion resistance. Designed for systems requiring rapid cycling (up to 5Hz) and low power consumption (3.5W max). Includes LED status indicator and surge protection circuitry. Requires ISO 8573-1 Class 3 compressed air (max 50mg/m³ oil content).
- Pneumatic cylinder sequencing in assembly lines
- Plastic injection molding machine clamp control
- Automated material handling systems
- Textile machinery tension control
- Semiconductor wafer handling vacuum/pressure switching
Installation Guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use 200-hour maintenance intervals in high-cycling applications.
Requires 20-30% duty cycle derating above 40℃ ambient temperature.
| Property | Property Value |
|---|---|
| sku | 4V11006BI-AM-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
