Airtac 4V100 Solenoid Valve 4V11006BIG-W
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006BIG-W Technical Details
- Model: 4V11006BIG-W
- Valve type: 4-way, 5-port (3-position closed center)
- Operation: Double solenoid, spring return
- Port size: PT1/4 (G1/4 optional)
- Effective area: 16.9 mm² (pilot piston)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Proof pressure: 1.2 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.8W (DC), 5.5VA (AC)
- Response time: ≤20ms (excitation), ≤30ms (reset)
- Ambient temperature: -5℃ to 80℃ (no freezing)
- Fluid temperature: 0–60℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Body material: Aluminum alloy (anodized)
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 520g ±5%
- Dimensions: 55mm (W) × 52mm (H) × 100mm (L)
- Flow characteristics: Cv=2.5 (Kv=2.8 m³/h)
- Port thread depth: 12mm (minimum engagement)
High-performance mid-size directional control valve with dual manual override and position indicator. Features corrosion-resistant construction with stainless steel internal springs and low-friction spool design. Requires 5-50μm filtered lubricated air (ISO 8573-1 Class 4). Compatible with ISO 15407-1 standard subplates.
- Multi-axis pneumatic actuator control in assembly lines
- Plastic injection molding machine clamping systems
- CNC machine tool chucking mechanisms
- Automated packaging line cylinder sequencing
- Semiconductor wafer handling robotics
- Food processing pneumatic circuit control (oil-mist lubricated)
Installation guidelines:
Mount horizontally with vibration damping pads. Maintain minimum 15mm clearance
between valves in manifold arrangements. Use Loctite 243 (medium strength)
on mounting screws. Perform initial 30-sec air purge before commissioning.
| Property | Property Value |
|---|---|
| sku | 4V11006BIG-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
