Airtac 4V200 Solenoid Valve 4V21006BI-W
AirTAC 4V21006BI-W Solenoid Valve Technical Specifications
- Model: 4V21006BI-W
- Type: 5/2-way double solenoid (bi-stable)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5%
- Dimensions: 55mm(L) × 45mm(W) × 75mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Power consumption: ≤2.5W (DC) / ≤4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 1.8
- Protection rating: IP67 (dust-tight and protected against temporary immersion)
- Port thread depth: 12mm
- Maximum switching frequency: 5Hz
High-performance bistable solenoid valve featuring energy-saving design with position memory function. The dual-coil structure maintains valve state without continuous power supply. Enhanced aluminum alloy body with hard anodizing treatment resists chemical corrosion and mechanical wear. Compatible with ISO 5599/1 mounting interface for modular systems.
- Automatic production line actuators
- Plastic injection molding machines
- Textile machinery controls
- Semiconductor manufacturing equipment
- Automated packaging systems
- Pneumatic clamping devices
Installation guidelines:
Mount in vibration-free environments using M5 mounting screws (max torque 1.2N·m).
Maintain minimum 20mm clearance above valve for heat dissipation.
Use 5-40μm precision filter with automatic drain.
Lubricated air (ISO VG32) recommended for extended seal life.
| Property | Property Value |
|---|---|
| sku | 4V21006BI-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
