Airtac 4V200 Solenoid Valve 4V21006D-AM
AirTAC 4V21006D-AM Solenoid Valve Technical Details
- Model: 4V21006D-AM (4V200 series)
- Valve type: 5/2-way, double solenoid operated
- Port configuration: G1/4" (ISO228/1 standard)
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.1W (DC), 3.5VA (AC)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile), replaceable cartridge design
- Ambient temperature: -5℃ to 60℃ (with anti-condensation measures above 40℃)
- Protection class: IP67 (dustproof & waterproof)
- Weight: 480g ±5% (including connectors)
- Dimensions: 96mm(L) × 32mm(W) × 60mm(H) (excluding mounting tabs)
- Port thread depth: 12mm (minimum engagement)
- Expected service life: 50 million cycles (under rated conditions)
High-flow bistable solenoid valve with dual coil redundancy, engineered for precision directional control in industrial automation. Features manual override button for system debugging and emergency operation. The full-metal pilot mechanism ensures stable performance in high-vibration environments. Requires ISO 8573-1:2010 [4:4:3] class compressed air with 5-50μm filtration.
- Pneumatic cylinder sequencing in assembly lines
- Clamping/unclamping systems in CNC machining centers
- Material handling robotics (end effector controls)
- Plastic injection molding machine actuators
- Semiconductor wafer handling equipment
- Automotive brake testing rigs
Installation protocol:
Mount using M4 screws with vibration-damping washers. Maintain minimum 20mm
clearance below valve for exhaust airflow. Use shielded cables for solenoid
connections in EMI-sensitive environments. Perform weekly manual cycling
during standby periods.
| Property | Property Value |
|---|---|
| sku | 4V21006D-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
