Airtac 4V200 Solenoid Valve 4V21006H-AM
AirTAC 4V21006H-AM Solenoid Valve Technical Specifications
- Full model designation: 4V210-06H-AM
- Valve type: 4V200 series 5-port/3-position closed center (double solenoid)
- Port configuration: Rc1/4 (G1/4 optional)
- Effective area ratio: 1:1.2 (for balanced pressure operation)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤25ms (at rated voltage)
- Seal material: Heat-resistant NBR (Nitrile) compound
- Ambient temperature: -5℃ to 80℃ (with 5℃ safety margin)
- Vibration resistance: ≤55Hz, 1.5mm double amplitude
- Weight: 400g ±2% (without fittings)
- Dimensions: 60mm(W) × 60mm(H) × 78mm(D)
- Port thread depth: 12mm (minimum engagement)
- Flow characteristics: Cv=1.8 (at 0.5MPa)
- Protection standard: IP67 (dustproof & temporary immersion)
This center-closed configuration valve features dual manual overrides and zero-pressure activation capability. The optimized spool geometry ensures ≤0.1MPa minimum operating pressure differential. Specialized in bi-directional cylinder control with position holding functionality. Includes built-in surge suppression and arc-quenching design for 500,000+ cycle durability.
- Plastic injection molding machine clamp controls
- Automated assembly line positioning systems
- Textile machinery tension balancing mechanisms
- Food processing pneumatic actuators (NSF-compliant version available)
- Hydraulic system pilot stage controls
Installation protocol:
Maintain ≥20mm clearance from heat sources. For vertical mounting,
orient coil upward. Always install downstream filter regulator (40μm)
with automatic drain. Lubrication: ISO VG32 turbine oil recommended
for humid environments.
| Property | Property Value |
|---|---|
| sku | 4V21006H-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
