Airtac 4V300 Solenoid Valve 4V31008B-W
2. Spool-type structure ensures excellent sealing performance and responsive actuation;
3. Three-position valves offer three center position configurations (exhaust-closed/exhaust-open/pressure-center);
4. Dual-solenoid two-position valves feature memory function for sustained state retention;
5. Specially honed inner bore minimizes friction resistance, enables low operating pressure, and extends service life;
6. Maintenance-free lubrication system eliminates external lubrication requirements;
7. Manifold-compatible design allows modular assembly, optimizing space utilization;
8. Integrated manual override facilitates installation and commissioning adjustments;
9. Multiple standard voltage options available for flexible integration.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V300
AirTAC 4V300 Solenoid Valve 4V31008B-W Technical Specifications
- Model: 4V31008B-W (4V300 series)
- Valve type: 5/2-way double solenoid pilot-operated
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Effective flow area: 17.0 mm² (Cv=1.7)
- Maximum flow rate: 850 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Seal materials: NBR (standard), optional VITON/FKM
- Weight: 350g ±5% (with connectors)
- Dimensions: 50mm(W) × 45mm(H) × 90mm(L)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A
- Manual override: Built-in emergency operation button
High-flow bistable solenoid valve with dual coil configuration for precise directional control in pneumatic systems. Features copper-free aluminum alloy body with hard anodizing treatment for corrosion resistance. Designed for 10 million cycle durability under rated conditions. Requires 5μm filtered lubricated/non-lubricated air (ISO8573-1 class 4).
- Automated packaging line cylinder control
- Plastic injection molding machine clamp systems
- Automotive assembly station actuators
- Bottle filling/capping machinery
- Textile machine tension control
- Semiconductor wafer handling robots
Installation guidelines:
Mount in vibration-free location with ±3° tolerance from vertical position.
Maintain 15mm clearance around valve for heat dissipation. Use M3.5 screws
with 0.6-0.8Nm torque for mounting. Always install downstream filter regulator.
Critical notes:
Do not apply voltage during piping installation. Allow 30-second
stabilization after power-on. For continuous operation, maintain
ambient temperature below 60℃ with duty cycle ≤80%.
| Property | Property Value |
|---|---|
| sku | 4V31008B-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
