Airtac 4V300 Solenoid Valve 4V31008BI-W
2. Spool-type structure ensures excellent sealing performance and responsive actuation;
3. Three-position valves offer three center position configurations (exhaust-closed/exhaust-open/pressure-center);
4. Dual-solenoid two-position valves feature memory function for sustained state retention;
5. Specially honed inner bore minimizes friction resistance, enables low operating pressure, and extends service life;
6. Maintenance-free lubrication system eliminates external lubrication requirements;
7. Manifold-compatible design allows modular assembly, optimizing space utilization;
8. Integrated manual override facilitates installation and commissioning adjustments;
9. Multiple standard voltage options available for flexible integration.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V300
AirTAC 4V300 Series Solenoid Valve 4V31008BI-W Technical Specifications
- Model Code: 4V31008BI-W
- Valve Type: 5/2-way (double solenoid operated)
- Port Thread: G1/8 (ISO228/1 standard)
- Effective Sectional Area: 18mm²
- Operating Pressure Range: 0.1–1.0 MPa
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power Consumption: 1.6W (DC), 3.5VA (AC)
- Response Time: ≤15ms (excitation), ≤20ms (reset)
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient Temperature: -5℃ to 80℃ (no freeze)
- Fluid Temperature: 0℃ to 60℃
- Protection Class: IP67 (dustproof & temporary immersion)
- Weight: 280g ±5g (including coil)
- Dimensions: 53mm(W) × 45mm(H) × 117mm(L)
- Port Positions: 5 ports (2 outputs, 2 exhausts, 1 supply)
- Manual Override: Built-in emergency operation button
High-flow directional control valve with dual-coil configuration for precise pneumatic circuit switching. Features aluminum alloy body with hard anodized surface treatment for enhanced corrosion resistance. The low-hysteresis design ensures stable operation in high-cycle applications (up to 5 million cycles). Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping control for CNC machining centers
- Material handling systems (rotary actuators control)
- Textile machinery thread tension regulation
- Bottle cap tightening mechanisms in beverage production
Installation Guidelines:
Mount using M4 screws with 45mm mounting pitch. Maintain minimum 30mm clearance below exhaust ports for unimpeded airflow. Use locknuts (included) to prevent vibration-induced loosening. Always install downstream air filter with 5μm rating.
Critical Note:
For DC models, ensure correct polarity (+/- markings). Continuous energization should not exceed 85% duty cycle. When using AC coils, install surge suppression modules for electrical noise reduction.
| Property | Property Value |
|---|---|
| sku | 4V31008BI-W |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
