Airtac 4V400 Solenoid Valve 4V41015-X0
2. Spool-type structure with excellent sealing performance and rapid response characteristics;
3. Three-position solenoid valve offers three center configuration options: closed center, exhausted center, and pressure center;
4. Dual-coil two-position configuration features latching (memory) function;
5. Precision-machined bore with low friction design ensures minimal actuation pressure and extended service life;
6. Maintenance-free operation without lubrication requirements;
7. Manifold-mountable design for space-efficient system integration;
8. Integrated manual override for simplified commissioning and troubleshooting;
9. Multiple standard voltage configurations available.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V400
AirTAC 4V400 Series Solenoid Valve 4V41015-X0 Technical Details
- Model: 4V41015-X0 (4V400 platform)
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (actuation), ≤20ms (release)
- Seal material: NBR (standard), optional FKM for high-temperature
- Ambient temperature: -20℃ to 60℃ (NBR), -10℃ to 80℃ (FKM)
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Protection class: IP67 (dust/water resistant)
- Manual override: Optional paddle-type operator
- Weight: 450g ±5% (with coil)
- Dimensions: 70mm(L) × 40mm(W) × 80mm(H)
- Port thread depth: 12mm (minimum engagement)
- Fluid compatibility: Compressed air (lubricated/non-lubricated)
High-flow directional control valve with optimized spool design for industrial automation. Features aluminum alloy body with hard anodized treatment for wear resistance. The dual-chamber design isolates electrical components from pneumatic flow paths, enhancing reliability in humid environments. Requires ISO 8573-1 class 3 compressed air (40μm filtration recommended).
- Pneumatic cylinder sequencing in assembly lines
- Packaging machine clamp control systems
- Textile machinery air circuit switching
- Automotive welding fixture positioning
- Food processing equipment actuators
Mounting guidelines:
Install with ±5° maximum deviation from vertical axis. Use flexible tubing
connections to minimize mechanical stress. Perform monthly exhaust port
cleaning in high-particulate environments.
| Property | Property Value |
|---|---|
| sku | 4V41015-X0 |
| Position | 5 Ports 2 Position |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
