Airtac F-HLQL-BF Rear End Hydraulic Cushion Complete Package F-HLQL20BF
AirTAC F-HLQL-BF Rear-Mounted Hydraulic Shock Absorber Kit F-HLQL20BF
- Model: F-HLQL20BF
- Series: HLQL-BF (Built-in buffer type)
- Rod diameter: Φ20mm
- Buffering capacity: 0.25 N·m/stroke
- Max. impact speed: 1.5 m/s
- Stroke adjustment range: 5-stage (5-25mm via rotating cap)
- Operating temperature: -10℃ to 80℃
- Oil viscosity grade: ISO VG15 hydraulic oil
- Max. side load: 40N
- Material: Aluminum alloy body with chrome-plated rod
- Seal type: HNBR seals with dust wiper
- Mounting orientation: Any direction (360° adjustable)
- Weight: 680g ±2%
- Dimensions: 98mm(L) × 32mm(W) × 32mm(H)
- Thread specifications: M10×1.25 mounting threads
- Surface treatment: Black anodized body
Precision-engineered hydraulic damper with 5-stage adjustable stroke, designed for industrial automation systems requiring controlled deceleration. Features self-compensating seals and anti-rotation mechanism for consistent performance in high-cycle applications. Includes pre-filled oil reservoir and anti-vibration locknuts.
- Pneumatic cylinder end-stroke shock absorption
- Packaging machine ram deceleration
- Robotic arm joint motion control
- CNC tool changer positioning systems
- Elevator car emergency buffer systems
Installation note:
Apply thread locker (LOCTITE 243 recommended) on mounting screws.
Perform 50 test cycles before full operation. Recalibrate every 50,000 cycles
using the hexagonal adjustment cap. Avoid side loads exceeding 10% of axial force.
| Property | Property Value |
|---|---|
| sku | F-HLQL20BF |
| Bore Diameter | <20mm> |
