Airtac F-TMIC Separate Guide Bracket F-TMICL25X125
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X125 Linear Guide Bracket Specifications
- Model: F-TMICL25X125
- Type: Single-axis linear guide carriage
- Bore diameter: 25mm (precisely honed)
- Stroke length: 125mm
- Mounting hole pattern: 60mm × 40mm rectangular array
- Material: Aluminum alloy 6063-T5
- Surface treatment: Hard anodized (25μm thickness)
- Radial load capacity: 1,800N (static), 1,200N (dynamic)
- Axial load capacity: 900N (static), 600N (dynamic)
- Operating temperature: -20℃ to 100℃
- Compatible rail type: SHS/SBR series 25mm linear guides
- Weight: 1.85kg ±2%
- Dimensions: 156mm(L) × 62mm(W) × 48mm(H)
Precision-machined linear motion component featuring dual-row ball bearing design for smooth travel and minimal friction. Includes pre-drilled mounting holes with counterbores for M6 fasteners (ISO 4762). Corrosion-resistant coating ensures durability in humid environments. Requires periodic lubrication with ISO VG15-grade grease.
- CNC router Z-axis support systems
- Automated optical inspection equipment
- 3D printer gantry alignment mechanisms
- Semiconductor wafer handling robots
- Pharmaceutical packaging line actuators
Installation note:
Align within 0.05mm/m using precision level during mounting.
Torque mounting bolts to 8-10Nm in crisscross pattern.
Perform run-in cycle (50 full strokes) before full-load operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X125 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
