Airtac F-TMIL Guide Unit Assembly F-TMIL12X125
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X125 Linear Guide Bracket Complete Package Specifications
- Model: F-TMIL12X125
- Type: Miniature linear guide carriage assembly
- Rail width: 12mm
- Stroke length: 125mm
- Carriage type: Double flange dual-block design
- Load capacity:
- Dynamic load (C): 1,250N
- Static load (C0): 2,400N
- Precision grade: Normal class (≤20μm/1000mm)
- Material:
- Rail: Carbon steel with black oxide coating
- Carriage: Aluminum alloy
- Balls: GCr15 bearing steel
- Sealing: Triple labyrinth seal with grease retention
- Mounting hole spacing: 40mm × 32mm (longitudinal × transverse)
- Weight: 385g ±5g
- Dimensions: 135mm(L) × 28mm(W) × 19.5mm(H)
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated with Molykote PG grease
Precision-engineered linear motion solution combining corrosion-resistant rails with low-friction ball recirculation. Features integrated mounting holes for direct machine frame attachment and protective sealing against particulate contamination. The compact profile enables space-efficient integration in high-density automation layouts.
- PCB component insertion machines
- Lab automation sample handling systems
- Semiconductor wafer inspection stages
- Medical imaging equipment sliding mechanisms
- Precision dispensing robot arms
Installation protocol:
Mount on machined surface with flatness ≤0.02mm/100mm.
Use 4x M4 screws (8.8 grade min.) torqued to 1.6N·m in cross pattern.
Avoid side-loading during alignment - use temporary support blocks.
Maintenance cycle: Relubricate every 500km travel or 6 months with ISO VG32 equivalent grease. Clean seals monthly in dusty environments using alcohol-free wipes.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X125 |
| Bore Diameter | 12mm |
| Stroke | 125mm |
