Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X100
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM Guide Bracket Kit F-TMIM12X100 Technical Details
- Model: F-TMIM12X100
- Series: TMIM Precision Linear Guide Series
- Material: Aluminum alloy (A6063-T5 base with hard anodized surface)
- Compatible rail size: TMIM12 (12mm rail width)
- Bracket length: 100mm ±0.2mm
- Mounting hole spacing: 80mm center-to-center
- Height: 25mm (from mounting surface to rail contact plane)
- Width: 20mm (perpendicular to rail direction)
- Weight: 0.25kg ±5%
- Static load capacity: 1,200N (radial), 600N (reverse radial)
- Dynamic load rating: 800N (radial), 400N (reverse radial)
- Surface hardness: HV400-450
- Operating temperature: -20℃ to 120℃
- Surface treatment: Black anodized (8-12μm thickness)
- Mounting screw specification: M4×8mm stainless steel (4 pcs included)
Precision-machined guide bracket assembly designed for TMIM series linear motion systems. Features dual-row ball contact design for reduced deflection, with hardened contact surfaces ensuring 0.01mm repeat positioning accuracy. Pre-lubricated with high-viscosity lithium grease for maintenance-free operation.
- CNC tool changer slide mechanisms
- 3D printer gantry alignment systems
- Semiconductor wafer handling robots
- Pharmaceutical packaging linear actuators
- Automated optical inspection (AOI) equipment
Installation protocol:
Mount using 0.6-0.8Nm torque on M4 screws. Align with rail using
dial indicator (max 0.05mm runout allowed). Apply thread locker to prevent
vibration-induced loosening in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X100 |
| Bore Diameter | 12mm |
| Stroke | 100mm |
