Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X125
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM12X125 Linear Motion Guide Bracket Kit Technical Details
- Model: F-TMIM12X125
- Type: Pre-assembled linear guide carriage kit with integrated bearing blocks
- Rail material: Cold-drawn carbon steel (SCM435 equivalent)
- Block material: Aluminum alloy ADC12 with hard anodized surface
- Bore diameter: Φ12mm (for shaft mounting)
- Effective stroke: 125mm ±0.1mm
- Static load capacity: 1,200N (radial), 600N (axial)
- Dynamic load rating: 800N (radial), 400N (axial)
- Mounting hole pattern: 30mm × 60mm rectangular array (M5 threaded)
- Operating temperature: -20℃ to 80℃
- Surface treatment: Black oxide coating (rail), MIL-A-8625 Type III anodizing (block)
- Included components: 1x guide rail, 2x bearing blocks, 4x M5×12 mounting screws, 2x end dampers
- Lubrication: Pre-lubricated with PTFE composite; maintenance interval: 500km travel or 6 months
- Repeat positioning accuracy: ±0.05mm
- Weight: 450g ±2%
- Dimensions: 125mm(L) × 25mm(W) × 20mm(H) (rail assembly)
Precision-engineered linear motion solution combining hardened steel rail and dual bearing blocks, optimized for high-cycle automation applications. Features zero-backlash ball recirculation design with 4-row angular contact structure, providing exceptional moment load resistance. Includes corrosion-resistant coatings and vibration-damping end stoppers for industrial environments.
- PCB assembly pick-and-place unit Z-axis guidance
- Laser cutting machine linear slide systems
- Automated test equipment probe positioning
- Medical device actuator assemblies
- Packaging machine vertical sealing mechanisms
Mounting protocol:
Apply 0.02-0.03mm preload using calibrated torque wrench (1.2N·m max).
Align rail parallelism within 0.01mm/m using master reference surface.
Thermal expansion compensation required for installations exceeding 1m length.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X125 |
| Bore Diameter | 12mm |
| Stroke | 125mm |
