Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X150
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM12X150 Linear Motion Guide Bracket Kit Technical Details
- Model: F-TMIM12X150
- Type: Precision linear guide support unit (pre-assembled)
- Material: Anodized aluminum alloy 6063-T5
- Bearing type: 4-row angular contact ball system
- Rail width: 12mm
- Total length: 150mm ±0.2mm
- Block dimensions: 28mm(W) × 20mm(H) × 150mm(L)
- Mounting hole pattern: 4×M4 threaded holes (6mm spacing)
- Dynamic load capacity: 1,850N
- Static load capacity: 2,400N
- Weight: 650g ±3%
- Surface hardness: HV 120-150
- Operating temperature: -30℃ to 120℃
- Preload level: Medium (C2 grade)
- Sealing: Dual-lip rubber seals (NBR material)
Precision-machined linear motion assembly combining guide rail and carriage block, optimized for high-rigidity applications. Features hardened steel balls (G10 grade) with chromium-plated rail surfaces (3-5μm thickness) for smooth reciprocating motion. Includes pre-applied lithium complex grease (NLGI #2) for maintenance-free operation up to 500km travel.
- CNC router Z-axis stabilization systems
- Automated optical inspection equipment stages
- 3D printer gantry alignment mechanisms
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
Installation guidelines:
Use 0.02mm precision level during mounting. Tighten bolts in cross pattern
(6-8Nm torque). Apply Loctite 243 to threads. Avoid side-load impacts exceeding
300N during operation. Relubricate every 2,000 operating hours using ISO VG15
turbine oil.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X150 |
| Bore Diameter | 12mm |
| Stroke | 150mm |
