Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X200
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM12X200 Linear Guide Bracket Kit Specifications
- Model: F-TMIM12X200
- Type: Pre-assembled linear guide carriage
- Material: Aluminum alloy 6063-T5 (hard anodized)
- Rail width: 12mm
- Stroke length: 200mm
- Load capacity: Static 12kN / Dynamic 6.5kN
- Precision grade: Normal grade (±0.1mm/m)
- Ball retainer: Stainless steel (SUS440C)
- Sealing: Triple labyrinth seal with grease retention
- Mounting hole pattern: 60mm × 40mm (4×M5 threaded holes)
- Surface treatment: MIL-A-8625 Type III anodizing
- Operating temperature: -20℃ to 120℃
- Weight: 1.85kg ±2%
- Dimensions: 230mm(L) × 42mm(W) × 34mm(H)
Precision-machined linear motion solution combining hardened guide rails with optimized ball circulation. Features corrosion-resistant construction with integrated dust protection, designed for medium-load automation systems requiring maintenance-free operation. Includes pre-loaded bearing blocks with alignment pins for simplified installation.
- CNC router Z-axis guidance systems
- Automated packaging line conveyors
- 3D printer gantry stabilization
- Semiconductor wafer handling robots
- Medical imaging equipment sliding mechanisms
Installation note:
Apply LOCTITE 243 to mounting screws (6.9Nm torque limit).
Requires parallel alignment within 0.05mm/m during rail installation.
Lubricate with ISO VG32-grade grease during maintenance.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X200 |
| Bore Diameter | 12mm |
| Stroke | <200mm> |
