Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X50
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM12X50 Linear Motion Guide Bracket Kit Specifications
- Model: F-TMIM12X50
- Type: Pre-assembled linear guide carriage
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Ball circuit system: 4-row circular arc groove design
- Dynamic load rating: 12.3 kN
- Static load rating: 24.5 kN
- Precision grade: Normal class (C) / High precision (H optional)
- Operating temperature: -20℃ to 120℃
- Surface treatment: Black oxide coating with rust preventive oil
- Sealing: Double-sided scrapers + End seals (IP54 equivalent)
- Lubrication: Pre-lubricated with VIGO grease No.2
- Mounting hole pattern: 32mm × 23mm rectangular array (M6 threaded)
- Weight: 0.85 kg ±2%
- Dimensions: 50mm(L) × 34mm(W) × 12.5mm(H)
Precision-ground linear motion unit combining rail and block, featuring optimized ball recirculation for smooth multi-directional movement. The hardened steel construction (HRC 58-62) ensures wear resistance in high-cycle applications. Integrated sealing system protects against particulate contamination up to 50μm.
- CNC tool changer sliding mechanisms
- 3D printer X/Y axis motion systems
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Automated optical inspection stages
Installation note:
Apply 4.9-6.9 N·m torque for M6 mounting screws.
Align rail mounting surface flatness within 0.02mm/m.
Relubricate every 1,000km travel or 6 months with ISO VG10-32 oil.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X50 |
| Bore Diameter | 12mm |
| Stroke | <50mm> |
