Airtac F-TMIM Guide Bracket Assembly Kit F-TMIM12X75
2. **Sleeve bearing version**: Optimized for radial load resistance in braking applications, delivering enhanced torsional rigidity; **Linear bearing version**: Engineered for lifting operations requiring high precision, heavy load capacity, and low-friction performance.
3. The proprietary guide frame structure supports multi-directional mounting configurations for flexible system integration. **Category**: Guide Frame **Brand**: AirTAC **Series**: F-TMIM
AirTAC F-TMIM12X75 Linear Guide Bracket Complete Package Specifications
- Model: F-TMIM12X75
- Type: Pre-assembled linear guide carriage with rail
- Rail width: 12mm
- Effective stroke length: 75mm
- Material: Carbon steel with chrome-plated rail
- Load capacity (dynamic): 1.2kN (C) / 0.8kN (C0)
- Accuracy grade: Normal grade (N)
- Preload level: Medium preload (Z0)
- Seal type: Integrated wiper seals with grease retention
- Mounting hole pattern: 32mm × 15mm (4×M4 threaded holes)
- Operating temperature: -10℃ to 80℃
- Surface hardness: HRC 58-62 (rail)
- Corrosion resistance: Standard anti-rust treatment
- Weight: 480g ±5% (complete assembly)
- Dimensions: 105mm(L) × 24mm(W) × 19.5mm(H)
Precision-ground linear motion solution combining low-friction movement with high rigidity. Features integrated sealing system preventing particulate ingress (IP54 equivalent). Includes pre-mounted rail with alignment marks and factory-applied lithium-complex grease. Compatible with pneumatic and electric drive systems.
- 3D printer Z-axis stabilization systems
- CNC tool changers
- Automated test equipment stages
- Medical imaging device sliding mechanisms
- Semiconductor wafer handling robots
Installation note:
Use 0.02mm grade parallelism gauge during mounting. Torque M4 screws
to 1.2N·m in cross pattern. Relubricate every 100km travel distance
using ISO VG32 equivalent grease.
| Property | Property Value |
|---|---|
| sku | F-TMIM12X75 |
| Bore Diameter | 12mm |
| Stroke | 75mm |
