Airtac SAU Standard Air Cylinder SAU32X130
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X130 Technical Details
- Model: SAU32X130
- Bore size: 32 mm
- Stroke: 130 mm
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic type (optional: front flange MF1, rear flange MB1, or foot mounting MP2)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Port size: G1/8 (ISO standard tapered thread)
- Ambient temperature range: -20℃ to +80℃
- Weight: 1.8 kg (without accessories)
- Dimensions:
- Total length (L): 248 mm (at mid-stroke position)
- External diameter: 32 mm ±0.5mm
- Mounting hole spacing: 40 mm (center-to-center)
- Rod end thread: M12×1.25 (male)
- Protection rating: IP65 (standard wiper design)
- Theoretical thrust: 257 N @0.5 MPa (extending side)
The SAU32X130 pneumatic cylinder delivers 32mm bore precision with 130mm stroke length, optimized for industrial automation requiring medium-force linear motion. Features triple chrome-plated piston rods for wear resistance and integrated magnetic sensor slots (model option: SAU32X130-M). Lubricator-free design with self-lubricating seals reduces maintenance frequency.
- Clamping fixtures in CNC machining centers
- Conveyor gate actuators in packaging lines
- Material positioning in automotive assembly
- Dough pressing mechanisms in food processing
- Paper feed systems in printing machinery
Installation guidelines:
Maintain 0.5mm minimum alignment tolerance between rod and load. Use flexible couplings for
side-loaded applications. For vertical mounting, implement anti-drop mechanisms using lock valves.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
| Property | Property Value |
|---|---|
| sku | SAU32X130 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 130mm |
