Airtac SAU Standard Air Cylinder SAU32X145
$47.26
Regular price
$54.76
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAU32X145
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
Installation Guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, use anti-drop locking nuts on piston rod.
Critical Note:
Requires 40μm filtered air with 1-10 mg/m³ oil mist content.
Avoid side load exceeding 30N during operation.
Max permissible lateral rod play: ±0.5mm.
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X145 Technical Details
- Model Code: SAU32X145-S
- Bore Size: 32 mm
- Stroke: 145 mm
- Operating Pressure: 0.05–1.0 MPa
- Piston Speed: 50–800 mm/s
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting Style: Basic type (MF1) with foot mounting holes
- Port Size: Rc1/8 (G1/8 optional)
- Ambient Temperature: -20℃ to 80℃
- Piston Rod Thread: M12×1.25
- Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal Type: NBR seals with wear-resistant ring
- Weight: 1.8 kg (with standard accessories)
- Dimensions: 230mm(L) × 50mm(W) × 50mm(H) (retracted position)
- Extended Length: 230mm + 145mm stroke = 375mm total
- Protection Class: IP54 (standard), IP67 (optional with rod cover)
A heavy-duty ISO 15552 compliant cylinder featuring dual-side magnetic field detection capability. The anodized barrel surface provides exceptional corrosion resistance, while the chrome-plated piston rod ensures smooth operation under lateral loads. Includes built-in auto-switch grooves for sensor mounting.
Industrial Applications:
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC machine tool workpiece positioning
- Automotive welding fixture actuators
- Food processing conveyor gate controls
Installation Guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, use anti-drop locking nuts on piston rod.
Critical Note:
Requires 40μm filtered air with 1-10 mg/m³ oil mist content.
Avoid side load exceeding 30N during operation.
Max permissible lateral rod play: ±0.5mm.
| Property | Property Value |
|---|---|
| sku | SAU32X145 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 145mm |
