Airtac SAU Standard Air Cylinder SAU32X15
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X15 Specifications
- Model: SAU32X15
- Type: Double-acting pneumatic cylinder (ISO 6432 compliant)
- Bore size: 32 mm (±0.1mm manufacturing tolerance)
- Stroke: 15 mm (adjustable stroke stopper optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Maximum thrust: 245 N at 0.63 MPa
- Port size: G1/8 (BSPP thread) with dual ports
- Cushioning: Progressive adjustable air cushion (both ends)
- Mounting types: Basic series (MF1 front flange, MB1 rear flange, MP4 foot mounting)
- Material: Aluminum alloy body (anodized), Chrome-plated piston rod (SUJ2 steel)
- Seal material: High-grade NBR (25±5 Shore A hardness)
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Piston speed: 50–700 mm/s (optimal range 100–500 mm/s)
- Weight: 0.88 kg (without accessories)
- Dimensions (L×W×H): 148 mm × 56 mm × 56 mm (including cushion screws)
- Rod thread: M10×1.25 (external thread at rod end)
- ISO standard: Compliant with ISO 6432:2015
Ultra-compact linear actuator engineered for precision short-stroke applications. Features dual adjustable pneumatic cushions for smooth end-of-stroke deceleration and precision ground inner bore (Ra≤0.4μm) for minimal friction. The hard chrome-plated piston rod incorporates a multi-layer sealing system with integrated wiper for dust protection. Designed for 500km+ service life under standard operating conditions.
- Micro-positioning in optical lens manufacturing
- Valve actuation in medical gas control systems
- Precision clamping in watchmaking CNC machines
- Paper feed mechanisms in high-speed printers
- Component insertion in PCB assembly lines
Operational guidance:
Maintain 0.3–1.0 MPa operating pressure for optimal efficiency. Use 40μm filtration
and automatic drain lubricators with ISO VG32 oil. Avoid side loads exceeding 15N
to prevent rod bearing wear. Perform monthly cushion adjustment checks in
high-cycle (>5Hz) applications.
| Property | Property Value |
|---|---|
| sku | SAU32X15 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <15mm> |
