Airtac SAU Standard Air Cylinder SAU32X190
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Series Standard Cylinder SAU32X190 Technical Details
- Model: SAU32X190
- Bore size: 32mm
- Stroke: 190mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (Standard) / Optional: MF1 front flange, MP2 side lug, etc.
- Port size: 1/8" NPT (G1/8 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (Nitrile rubber) standard / Optional PU seals
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized surface
- Weight: Approx. 1.56 kg (without accessories)
- Dimensions (L×W×H):
- Total length: 283mm (at mid-stroke position)
- Body diameter: 50mm
- Rod end thread: M12×1.25
- ISO standard: Compliant with ISO 6432
- Protection class: IP65 (Dust-tight & water jet resistant)
The SAU32X190 medium-duty cylinder features a compact design with enhanced side load capacity through integrated guide ribs. Its double-acting operation and precision honed tube ensure smooth linear motion, while the chrome-plated piston rod resists corrosion in humid environments. The cylinder incorporates a magnetic piston for position sensing compatibility.
- Automated packaging machinery actuation
- CNC machine tool clamping systems
- Conveyor belt tensioning mechanisms
- Printing press paper feed controls
- Automotive assembly line positioning
Installation guidelines:
Use alignment jigs during mounting to prevent rod bending. Lubricate with ISO VG32 hydraulic oil
before initial operation. Maintain 0.3m clearance from welding operations to prevent seal degradation.
Critical note:
Avoid lateral forces exceeding 15N on piston rod. Install rod-end support when handling
eccentric loads above 2kg. Maximum side load capacity: 30N at full extension.
| Property | Property Value |
|---|---|
| sku | SAU32X190 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 190mm |
