Airtac SAU Standard Air Cylinder SAU32X290
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X290 Specifications
- Model: SAU32X290
- Type: ISO 6432 compliant single-acting/double-acting cylinder
- Bore size: 32 mm
- Stroke: 290 mm (±0.5 mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 12 mm (chrome-plated steel)
- Cushioning type: Adjustable air cushion at both ends
- Port size: 1/4" NPT (G1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (NBR seals compatible with ISO VG32 oil)
- Mounting options: Basic type (no mount), MF1 front flange, MP2 side lug
- Weight: 2.85 kg (double-acting), 2.72 kg (single-acting)
- Dimensions (L×W×H):
- Extended length: 582 mm
- Retracted length: 292 mm
- Body diameter: 32 mm ±0.5
- Mounting flange: 60×60 mm
- ISO standard: ISO 6432, VDMA 24562
- Protection class: IP65 (with wiper seal)
A high-precision industrial cylinder featuring dual adjustable pneumatic cushions for smooth end-of-stroke deceleration. The anodized aluminum construction provides corrosion resistance in humid environments, while the magnetic piston version (SAU32X290-M) enables position sensing. Requires 40μm filtered compressed air with ≤5% relative humidity.
- Plastic injection molding machine ejectors
- Automated conveyor gate actuators
- CNC machine tool clamping systems
- Textile machinery tension control
- Automotive assembly line positioning
Installation guidelines:
Align cylinder axis within 0.2° angular tolerance. For vertical mounting,
use double-acting configuration with flow control valves. Lubricate rod
every 500km of cumulative stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | SAU32X290 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 290mm |
