Airtac SAU Standard Air Cylinder SAU32X30
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X30 Technical Details
- Model: SAU32X30 (Standard Aluminum Air Cylinder)
- Bore size: 32mm (±0.5mm tolerance)
- Stroke: 30mm (Standard stroke options: 10-300mm)
- Operating pressure: 0.05-1.0 MPa
- Action type: Double-acting
- Cushioning type: Adjustable buffer (both ends)
- Mounting style: Basic type (MF1/MF2 optional)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-750 mm/s
- Material: Aluminum alloy body (A6063-T5), CR seal ring
- Weight: 0.82kg (Without accessories)
- Dimensions: 130mm(L) × 32mm(Bore Ø) × 42mm(Mounting width)
- Rod thread: M10x1.25 (External thread)
- Lubrication: Pre-lubricated (Use ISO VG32 oil if required)
- Protection class: IP54 (Standard sealing)
The SAU32X30 features precision honed tubing with hard anodized surface treatment (25μm thickness) for enhanced wear resistance. Its dual-piston design ensures smooth linear motion with ≤0.5mm lateral play. The chrome-plated piston rod (HRC45-50 hardness) integrates a magnetic ring (SN series compatible) for position sensing. Requires 40μm filtered compressed air with ≤1mg/m³ oil content.
- Clamping mechanisms in CNC fixture systems
- Material handling pushers in conveyor lines
- Valve actuation in food processing machinery
- Precision alignment in semiconductor wafer handling
- Packaging machine lid closure systems
Installation protocol:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use rod-down position with speed control. Lubricate through air supply at 1-2 drops/m³
for optimal seal life. Annual rod seal inspection recommended.
| Property | Property Value |
|---|---|
| sku | SAU32X30 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 30mm |
