Airtac SAUJ63 Adjustable Pneumatic Cylinder SAUJ63X100-100S
$92.81
Regular price
$100.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ63X100-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of SAUJ63 Adjustable Cylinder:
1. Compliant with Airtac Enterprise Standard Cylinder specifications;
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
Operational note:
Lubricate through air port (ISO VG32 recommended) before initial use.
Avoid exceeding 90% stroke adjustment during high-speed (>500mm/s) operations.
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
AirTAC SAUJ63 Adjustable Stroke Cylinder SAUJ63X100-100S Technical Details
- Model Code: SAUJ63X100-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63mm
- Stroke: 100mm (adjustable range: 0-100mm)
- Rod diameter: 20mm
- Operating pressure: 0.05-1.0 MPa
- Max thrust: 1,960N at 0.63MPa
- Cushioning: Adjustable with external cushioning screws
- Mounting style: Basic type (no pre-mounted brackets)
- Port size: G1/4 (ISO standard)
- Ambient temperature: -10℃ to 80℃
- Piston material: Aluminum alloy hard anodized
- Rod material: Chrome-plated steel
- Seal type: NBR + PU hybrid seals
- Weight: 2.8kg ±3%
- Dimensions (L×W×H):
- Retracted length: 236mm
- Extended length: 336mm
- Body width: 80mm
- Mounting height: 63mm
Precision stroke-adjustable cylinder featuring dual external adjustment screws for fine-tuning stroke length without disassembly. The hardened aluminum construction provides corrosion resistance in humid environments while maintaining lightweight performance (30% lighter than steel equivalents). Includes magnetic piston for position sensing compatibility.
Industrial Applications:
- Variable position clamping in CNC tool changers
- Adjustable press mechanisms in plastic injection molding
- Material handling systems requiring variable reach
- Packaging line product height compensation
- Automated welding positioners
Operational note:
Lubricate through air port (ISO VG32 recommended) before initial use.
Avoid exceeding 90% stroke adjustment during high-speed (>500mm/s) operations.
| Property | Property Value |
|---|---|
| sku | SAUJ63X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
