Description
Product Description of SAUJ63 Adjustable Cylinder:
1. Compliant with Airtac Enterprise Standard Cylinder specifications;
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
Installation note:
For optimal performance, maintain 0.5-1mm clearance between adjustment lock nuts. Lubricate with ISO VG32 hydraulic oil. Avoid side load exceeding 30N. Maximum permissible rod end play: ±0.5mm.
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
AirTAC SAUJ63 Adjustable Cylinder SAUJ63X100-75 Technical Specifications
- Model: SAUJ63X100-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Standard stroke: 100mm
- Adjustment range: 0-75mm stroke reduction
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (MF1) with optional foot/mounting brackets
- Port size: G1/8 (NPT1/8 optional)
- Ambient temperature: -10℃ to 80℃
- Material: Aluminum barrel, CRCA steel rod
- Rod end type: Male thread M16×1.5
- Weight: 2.8kg (with standard accessories)
- Dimensions: 215mm(L) × 80mm(W) × 80mm(H) (at full extension)
- ISO standard: 15552 compliant
- Protection class: IP54 (standard seals)
Precision-adjustable pneumatic cylinder featuring a unique dual-lock stroke adjustment mechanism with visual position indicators. The hardened chrome piston rod and wear-resistant seals enable reliable mid-position stopping capability, making it ideal for variable stroke applications. Includes built-in magnetic sensor slots (M5x0.8) for position feedback.
Typical Applications:
- Variable height work platforms in assembly lines
- Adjustable clamping fixtures for CNC machining
- Packaging machine product height compensation
- Automated door stroke limitation systems
- Press tool depth control applications
Installation note:
For optimal performance, maintain 0.5-1mm clearance between adjustment lock nuts. Lubricate with ISO VG32 hydraulic oil. Avoid side load exceeding 30N. Maximum permissible rod end play: ±0.5mm.
| Property | Property Value |
|---|---|
| sku | SAUJ63X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
