Airtac SAUJ63 Adjustable Pneumatic Cylinder SAUJ63X1000-100S
$220.76
Regular price
$228.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ63X1000-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of SAUJ63 Adjustable Cylinder:
1. Compliant with Airtac Enterprise Standard Cylinder specifications;
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
Installation note:
Requires rigid mounting structure due to extended stroke length.
Maintain 0.5-1mm alignment tolerance between rod end and load.
Use support guides for strokes exceeding 800mm. Lubricate adjustment
threads monthly with ISO VG32 hydraulic oil.
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
AirTAC SAUJ63X1000-100S Adjustable Cylinder Specifications
- Model: SAUJ63X1000-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 1000mm (adjustable via external stopper)
- Adjustment range: 0-100mm fine tuning (100S suffix)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic type (no fixed mounting)
- Port size: G1/2 (ISO228/1 standard)
- Operating temperature: -10℃ to 80℃
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Weight: 9.8kg ±2% (excluding accessories)
- Dimensions: 1365mm(L) × 80mm(W) × 80mm(H) (full extension)
- Rod thread: M16×1.5 (external)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (DOP oil mist compatible)
High-precision long-stroke cylinder with external stroke adjustment capability, featuring dual-position locking mechanism for mid-stroke positioning. The 100S variant includes a micrometer-style adjustment collar with 0.1mm graduation marks. Anti-rotation design maintains piston orientation during partial stroke operations.
Typical Applications:
- Variable height positioning in automotive assembly jigs
- Material handling systems requiring adjustable lift heights
- Plastic injection molding machine ejector mechanisms
- Large-format CNC router tool changers
- Solar panel production line alignment systems
Installation note:
Requires rigid mounting structure due to extended stroke length.
Maintain 0.5-1mm alignment tolerance between rod end and load.
Use support guides for strokes exceeding 800mm. Lubricate adjustment
threads monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SAUJ63X1000-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
