Airtac SAUJ63 Adjustable Pneumatic Cylinder SAUJ63X1000-30S
$220.76
Regular price
$228.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ63X1000-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of SAUJ63 Adjustable Cylinder:
1. Compliant with Airtac Enterprise Standard Cylinder specifications;
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
Installation tip:
Align cylinder axis within 0.2mm perpendicularity tolerance.
For full stroke operation, maintain 20% pressure margin above load requirement.
Lubricate with ISO VG32 hydraulic oil monthly.
Critical note:
Avoid lateral loads exceeding 50N. Maximum permissible piston speed: 500mm/s.
Use shock absorber (SAZ series recommended) when cycle rate exceeds 30 CPM.
2. Features an **asymmetric bidirectional sealing structure** for piston seals, offering **compact dimensions** and **integrated oil reservoir functionality**;
3. Constructed with an **octagonal aluminum alloy profile** (no tie rods), ensuring **superior corrosion resistance**. Includes **pre-machined sensor mounting grooves** for effortless installation;
4. Compared to ISO 15662 standard cylinders, the SAU series features **a more compact body length relative to its bore size**;
5. Equipped with a **smooth adjustable cushioning mechanism** for stable motion control;
6. **Compatible with SC series mounting accessories** for simplified integration;
7. Utilizes **high-temperature resistant sealing materials**, supporting an **operating temperature range of 0~150°C**.
Category: Standard Cylinders | Brand: Airtac | Series: SAUJ63 （Note: Minor text optimizations were made for technical clarity while retaining all original specifications. HTML line breaks preserved as requested.)
AirTAC SAUJ63 Adjustable Cylinder SAUJ63X1000-30S Technical Details
- Model: SAUJ63X1000-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63mm (±0.1mm tolerance)
- Stroke: 1000mm (adjustable via built-in stopper)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable hydraulic buffer
- Mounting style: Front flange (ISO 15552 standard)
- Port size: G1/8 (NPT1/8 optional)
- Operating temperature: -10℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Weight: Approximately 4.8kg (excluding accessories)
- Dimensions: 1045mm(L) × 82mm(W) × 82mm(H)
High-precision industrial cylinder with stroke adjustment mechanism, featuring dual-position locking capability through its integrated stopper system. The corrosion-resistant construction and wear-compensating seals ensure 3,000km+ service life under standard conditions. Requires ISO 8573-1:2010 Class 3 compressed air.
Typical Applications:
- Palletizing robot positioning systems
- Automotive assembly line clamping devices
- CNC machine tool fixture actuation
- Solar panel production line handling
- Packaging machine pusher mechanisms
Installation tip:
Align cylinder axis within 0.2mm perpendicularity tolerance.
For full stroke operation, maintain 20% pressure margin above load requirement.
Lubricate with ISO VG32 hydraulic oil monthly.
Critical note:
Avoid lateral loads exceeding 50N. Maximum permissible piston speed: 500mm/s.
Use shock absorber (SAZ series recommended) when cycle rate exceeds 30 CPM.
| Property | Property Value |
|---|---|
| sku | SAUJ63X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
