Airtac SGD Series Steel Tube Type Double Rod Cylinder SGD125X175
$256.33
Regular price
$263.83
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGD125X175
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 15552 standard (supersedes ISO 6431 specification) for cylinder manufacturing;
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
Installation note:
Maintain parallel alignment of twin rods during assembly. Use precision alignment jigs
for mounting. Apply anti-seize compound on rod threads when operating in corrosive environments.
Minimum 20μm filtration required for optimal seal life.
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
AirTAC SGD125X175 Steel Tube Type Double Rod Cylinder Specifications
- Model: SGD125X175
- Type: Double rod, double-acting cylinder (steel construction)
- Bore size: 125mm
- Stroke: 175mm
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 40mm (chrome-plated steel)
- Rod end thread: M20×1.5 (both ends)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (BSPP thread)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR/PU compound (oil & abrasion resistant)
- Weight: 8.5kg ±2% (excluding accessories)
- Dimensions: 350mm(L) × 148mm(W) × 148mm(H) (at mid-stroke)
- Mounting: ISO/VDMA standard mounting patterns (front flange & rear foot)
- Max theoretical force: 1570N @0.63MPa (extending/retracting)
- Lubrication: Pre-lubricated (recommended relubrication every 500km stroke)
High-rigidity steel cylinder with twin piston rods for exceptional moment resistance. Features dual cushion adjustment screws for precise deceleration control. Hard-chromed rods with multi-lip seals ensure leak-free operation in heavy-load applications. Optional magnetic piston version available for position sensing.
Typical Applications:
- Press machine clamping mechanisms
- Automated foundry equipment (core extraction)
- Heavy-duty material transfer systems
- Paper roll handling machinery
- Plastic injection mold clamping
Installation note:
Maintain parallel alignment of twin rods during assembly. Use precision alignment jigs
for mounting. Apply anti-seize compound on rod threads when operating in corrosive environments.
Minimum 20μm filtration required for optimal seal life.
| Property | Property Value |
|---|---|
| sku | SGD125X175 |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 175mm |
