Compendium of SAU Series Standard cylinder manufactured by our enterprise
With adjustable air buffer on the front and back cover
No tie rod cylinder
The cylinder barrel is aluminum profile with hard anodizing treatment.
Four kinds of cylinder joints:
- I Knuckle
- Y Knuckle
- F Floating Joint
- Universal Joint
Convenient and fast fix sensor switch
Sensor switch can be directly fixed onto the groover of the cylinder, which is convenient and fast. the counterpart sensor switch type is: CMSG, DMSG, EMSG
Multi-mounting accessories
Multi-type cylinder
SAU: Double acting type SAUD: Double rod type
SAUJ: Adjustable stroke type SAUF: With valve type
Criteria for selection: Cylinder thrust
1. When load changes in the work, the cylinder with abundant output capacity shall be selected.
2. Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion.
3. Necessary protection measure shall be taken in the environment with higher humidity, much dust or water drops, oil dust and welding dregs.
4. Dirty substances in the pipe must be eliminated before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.
5. The medium used by cylinder shall be filtered to 40um or below.
6. Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.
7. The cylinder shall be carried out test run without load before application. Prior to run, buffer shall be turned to the minimum and gradually released to avoid the damage on cylinder caused by excessive impact.
8. The cylinder shall avoid the influence of side load in operation to maintain the normal work of cylinder and extend the service life.
9. If the cylinder is dismantled and stored for a long time, please conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports.
Cylinder thrust (Unit: Newton(N))
| Bore size | Rod size | Acting type | Acting area(mm²) | Operating pressure(MPa) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.1 | 0.2 | 0.3 | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 0.9 | ||||
| 32 | 12 | Double acting Push side | 804 | 80.4 | 160.8 | 241.2 | 321.6 | 402.0 | 482.4 | 562.8 | 643.2 | 723.6 |
| Double acting Pull side | 690 | 69.0 | 138.0 | 207.0 | 276.0 | 345.0 | 414.0 | 483.0 | 552.0 | 621.0 | ||
| 40 | 16 | Double acting Push side | 1256 | 125.6 | 251.2 | 376.8 | 502.4 | 628.0 | 753.6 | 879.2 | 1004.8 | 1130.4 |
| Double acting Pull side | 1055 | 105.5 | 211.0 | 316.5 | 422.0 | 527.5 | 633.0 | 738.5 | 844.0 | 949.5 | ||
| 50 | 20 | Double acting Push side | 1963 | 196.3 | 392.6 | 588.9 | 785.2 | 981.5 | 1177.8 | 1374.1 | 1570.4 | 1766.7 |
| Double acting Pull side | 1649 | 164.9 | 329.8 | 494.7 | 659.6 | 824.5 | 989.4 | 1154.3 | 1319.2 | 1484.1 | ||
| 63 | 20 | Double acting Push side | 3117 | 311.7 | 623.4 | 935.1 | 1246.8 | 1558.5 | 1870.2 | 2181.9 | 2493.6 | 2805.3 |
| Double acting Pull side | 2803 | 280.3 | 560.6 | 840.9 | 1121.2 | 1401.5 | 1681.8 | 1962.1 | 2242.4 | 2522.7 | ||
| 80 | 25 | Double acting Push side | 5026 | 502.6 | 1005.2 | 1507.8 | 2010.4 | 2513.0 | 3015.6 | 3518.2 | 4020.8 | 4523.4 |
| Double acting Pull side | 4536 | 453.6 | 907.2 | 1360.8 | 1814.4 | 2268.0 | 2721.6 | 3175.2 | 3628.8 | 4082.4 | ||
| 100 | 25 | Double acting Push side | 7853 | 785.3 | 1570.6 | 2355.9 | 3141.2 | 3926.5 | 4711.8 | 5497.1 | 6282.4 | 7067.7 |
| Double acting Pull side | 7362 | 736.2 | 11472.4 | 2208.6 | 2944.8 | 3681.0 | 4417.2 | 5153.4 | 5889.6 | 6625.8 | ||
Product feature
- Standard cylinder manufactured by our enterprise.
- The seal of piston adopts heterogeneous two way seal structure. It's dimension is tight and it has the function of oil reservation.
- It is no tie rod cylinder. The cylinder barrel is aluminum profile with hard anodizing treatment.
- Compared with ISO15552 standard cylinder, SAU series cylinder with the same bore size is shorter.
- The buffer adjustment of cylinder is smooth and steady.
- Mounting accessories are the same as SC series.
- The seal material with high temperature resistance is adopted, operating temperature range is 0~150℃.
Specification
| Parameter | 32mm | 40mm | 50mm | 63mm | 80mm | 100mm |
|---|---|---|---|---|---|---|
| Acting type | Double acting | Double acting | Double acting | Double acting | Double acting | Double acting |
| Fluid | Air (to be filtered by 40um filter element) | |||||
| Mounting type | SAU: Basic FA FB CA CB LB | |||||
| SAUD, SAUJ: Basic FA LB | ||||||
| Operating pressure | 0.15~1.0MPa(22~145psi)(1.5~10.0bar) | |||||
| Proof pressure | 1.5MPa(215psi)(15bar) | |||||
| Temperature ℃ | -20~70 | |||||
| Speed range mm/s | 30~800 | |||||
| Stroke tolerance | 0~250+0.2, 251~1000+1.5, 1001~1500+2.0 | |||||
| Cushion type | Variable cushion | |||||
| Adjustable cushion stroke | 21 | 21 | 21 | 21 | 28 | 29 |
| Port size[Note1] | 1/8" | 1/4" | 1/4" | 3/8" | 3/8" | 1/2" |
[Note1] PT thread, G thread are available.
Added) Refer to P362 for detail of sensor switch.
Stroke
| Bore size (mm) | Standard stroke (mm) | Max. std stroke | Max. stroke |
|---|---|---|---|
| 32 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 | 1000 | 1800 |
| 40 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1200 | 1800 |
| 50 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1200 | 1800 |
| 63 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 1800 |
| 80 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 1800 |
| 100 | 25 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 1800 |
[Note] Consult us for non-standard stroke.
Model code
SAU 50 × 50 S□ □ □
SAUD 50 × 50 S□ □ □
SAUJ 50 × 50 - 20 S□ □ □
| No. | Content | Options | Description |
|---|---|---|---|
| ① Model | SAU | SAU: Double acting type SAUD: Double rod type SAUJ: Adjustable stroke type |
32/40/50/63/80/100 |
| ② Bore size | 32/40/50/63/80/100 | ||
| ③ Stroke | Refer to stroke table for details | ||
| ④ Adjustable stroke | SAUJ type only: 10/20/30/40/50/75/100 | No this code for other types | |
| ⑤ Magnet | Blank: Without magnet S: With magnet |
Blank: Without magnet S: With magnet |
|
| ⑥ Mounting type[Note1] | Blank/LB/FA/FB/CA/CB/1 | 1: For SAUD type only | |
| ⑦ Seals Material | Blank: TPU H: Viton N: NBR |
Blank: TPU H: Viton N: NBR |
|
| ⑧ Thread type | Blank: PT G: G |
Blank: PT G: G |
[Note1] The accessories are the same as SC series, please refer to page 41~44 for details.
Inner structure and material of major parts
| NO. | Item | Material |
|---|---|---|
| 1 | Rod nut | Carbon steel |
| 2 | Piston rod | Carbon steel with 20um chrome plated |
| 3 | Front cover packing | TPU |
| 4 | Bushing | Wear resistant material |
| 5 | Front cover | Aluminum alloy |
| 6 | Cushing O-ring | NBR |
| 7 | Cushion gasket | TPU |
| 8 | Barrel | Aluminum alloy |
| 9 | Piston | Aluminum alloy |
| 10 | Piston rod O-ring | NBR |
| 11 | Piston seal | NBR |
| 12 | Magnet | Plastic |
| 13 | Wear ring | Wear resistant material |
| 14 | Bolt | Carbon steel |
| 15 | Back cover | Aluminum alloy |
| 16 | Tie-rod nut | Carbon steel |
Note: inner structure & material data sheet is based on certain bore size. Please contact AirTAC if you need inner structure & material data sheet for specific bore size.
Dimensions
| Bore size Item | A | AB | AC | AD | AE | B | D | DA | E | EA | F | FA | M | MA | H | K | KA | KB | P | PA | PB |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 32 | 140 | 47 | 93 | 27.5 | 27.5 | 45 | 12 | 32 | M10×1.25 | 22 | 17 | 6 | 28 | 15 | 10 | M6×1.0 | 16 | 33 | 1/8" | 14 | 5.5 |
| 40 | 142 | 49 | 93 | 27.5 | 27.5 | 50 | 16 | 34 | M12×1.25 | 24 | 17 | 7 | 32 | 15 | 13 | M6×1.0 | 16 | 37 | 1/4" | 15 | 6 |
| 50 | 150 | 57 | 93 | 27.5 | 27.5 | 62 | 20 | 42 | M16×1.5 | 32 | 23 | 8 | 38 | 15 | 17 | M6×1.0 | 16 | 47 | 1/4" | 17 | 8.5 |
| 63 | 153 | 57 | 96 | 27.5 | 27.5 | 75 | 20 | 42 | M16×1.5 | 32 | 23 | 8 | 38 | 15 | 17 | M8×1.25 | 16 | 56 | 3/8" | 15 | 9.5 |
| 80 | 182 | 75 | 107 | 33 | 33 | 94 | 25 | 54 | M20×1.5 | 40 | 26 | 10 | 47 | 21 | 22 | M10×1.5 | 18 | 70 | 3/8" | 19.5 | 10 |
| 100 | 188 | 75 | 113 | 33 | 33 | 112 | 25 | 54 | M20×1.5 | 40 | 26 | 10 | 47 | 21 | 22 | M10×1.5 | 18 | 84 | 1/2" | 16.5 | 11 |
Remark: The dimensions of magnet type cylinder are the same as non-magnet type cylinder.
| Bore size\Item | A(SAUD) | A(SAUJ) | AB | AC | DA | DB | E | FA |
|---|---|---|---|---|---|---|---|---|
| 32 | 187 | 182 | 47 | 93 | 32 | 27 | M10X1.25 | 6 |
| 40 | 191 | 185 | 49 | 93 | 34 | 28 | M12X1.25 | 7 |
| 50 | 207 | 194 | 57 | 93 | 42 | 29 | M16X1.5 | 8 |
| 63 | 210 | 197 | 57 | 96 | 42 | 29 | M16X1.5 | 8 |
| 80 | 257 | 238.5 | 75 | 107 | 54 | 35.5 | M20X1.5 | 10 |
| 100 | 263 | 244.5 | 75 | 113 | 54 | 35.5 | M20X1.5 | 10 |
Remark:
1. The dimensions of magnet type cylinder are the same as non-magnet type cylinder.
2. The unmarked dimension is the same as SAU standard type.
SAUF Series—With valve type
Product feature
- For Standard Cylinders: use 4M210 valve for bore size 32, 40 & 50; 4M310 valve for bore size 63, 80 & 100mm.
- Individually control, no need for extra solenoid valves.
- Installation time & space saving; suitable for decentralize installation in large system.
- Options of mounting accessories & easy installation.
Stroke
| Bore size | Standard stroke(mm) | Mini. stroke | Max. std stroke | Max. stroke |
|---|---|---|---|---|
| 32 | 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 | 50 | 1000 | 2000 |
| 40/50 | 50 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 50 | 1200 | 2000 |
| 63/80/100 | 75 80 100 125 150 160 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 75 | 1500 | 2000 |
[Note] Consult us for non-standard stroke.
Specification
| Parameter | 32mm | 40mm | 50mm | 63mm | 80mm | 100mm |
|---|---|---|---|---|---|---|
| Cylinder specification | ||||||
| Bore size(mm) | 32 | 40 | 50 | 63 | 80 | 100 |
| Acting type | Double acting | Double acting | Double acting | Double acting | Double acting | Double acting |
| Fluid | Air (to be filtered by 40um filter element) | |||||
| Mounting type | Basic FA FB CA CB LB | |||||
| Operating pressure | 0.15~1.0MPa(22~145psi)(1.5~10.0bar) | |||||
| Proof pressure | 1.5MPa(215psi)(15bar) | |||||
| Temperature ℃ | -20~70 | |||||
| Speed range mm/s | 30~800 | |||||
| Stroke tolerance | 0~250+0.2, 251~1000+1.5, 1001~1500+2.0 | |||||
| Cushion type | Variable cushion | |||||
| Adjustable cushion stroke | 21 | 21 | 21 | 21 | 28 | 29 |
| Port size | 1/8" | 1/4" | 1/4" | 3/8" | 3/8" | 1/2" |
| PU tube size(OD×ID) | Φ8×Φ5 | Φ8×Φ5 | Φ8×Φ5 | Φ8×Φ5 | Φ10×Φ6.5 | Φ10×Φ6.5 |
| Solenoid valve specification | ||||||
| Model | 4M210-06 & 4M210-08 | 4M310-08 & 4M310-10 | ||||
| Fluid | Air (to be filtered by 40um filter element) | |||||
| Acting type | Internal piloted | |||||
| Port size [Note1] | In=Exhaust=1/8" & In=1/4" Exhaust=1/8" | In=Exhaust=1/4" & In=PT3/8 Exhaust=1/4" | ||||
| Orifice size | 4M210-06: 14.0mm(Cv=0.78) 4M210-08: 16.0mm(Cv=0.89) |
4M310-08: 25.0mm²(Cv=1.40) 4M310-10: 30.0mm(Cv=1.68) |
||||
| Valve type | 5 port 2 position | |||||
| Operating pressure | 0.15~0.8MPa(21~114psi) | |||||
| Proof pressure | 1.2MPa(175psi) | |||||
| Temperature ℃ | -20~70 | |||||
| Body material | Aluminum alloy | |||||
| Lubrication [Note2] | Not required | |||||
| Max. frequency [Note3] | 5 cycle/sec | 4 cycle/sec | ||||
| Coil specification | ||||||
| Standard voltage | AC220V, AC110V, AC24V, DC24V, DC12V | |||||
| Scope voltage | AC: ±15% DC: ±10% | |||||
| Power consumption | AC: 3.5VA DC: 3.0W | |||||
| Protection | IP65(DIN40050) | |||||
| Temperature classification | B Class | |||||
| Electrical entry | Terminal, Grommet | |||||
| Activating time | 0.05 sec and below | |||||
[Note1] PT thread, G thread are available.
[Note2] It can't stop in the midway of lubricating. Lubricants like ISO VG32 or equivalent are recommended.
[Note3] The maximum actuation frequency is in the no-load state.
Added) Refer to P362 for detail of sensor switch.
Model code
SAUF 50×1000 S□ -06 A□ □
| No. | Content | Options | Description |
|---|---|---|---|
| ① Model | SAUF | SAUF: Double acting with valve type | 32/40/50/63/80/100 |
| ② Bore size | 32/40/50/63/80/100 | ||
| ③ Stroke | Refer to stroke table for details | ||
| ④ Magnet | Blank: Without magnet S: With magnet |
Blank: Without magnet S: With magnet |
|
| ⑤ Mounting type[Note1] | Blank | ||
| LB | |||
| FA | |||
| FB | |||
| CA | |||
| CB | |||
| ⑥ Port size | 06: 1/8" 08: 1/4" 10: 3/8" |
||
| ⑦ Voltage | A: AC220V B: DC24V C: AC110V E: AC24V F: DC12V |
||
| ⑧ Electrical entry | Blank: Terminal I: Grommet |
||
| Thread type | Blank: PT G: G |
[Note1] The accessories are the same as SC series, please refer to page 41~44 for details.
Inner structure
- 4M series solenoid valve
- Unite block
- APC series tube connector
- PU tube
- SAU series cylinder
- APH series tube connector
Note: inner structure & material data sheet is based on certain bore size. Please contact AirTAC if you need inner structure & material data sheet for specific bore size.
Dimensions
Pull when energized Push when energized
| Bore size\Item | A | AB | AC | AD | AE | AF | AG | B | BA | BC | BD |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 32 | 140 | 47 | 93 | 27.5 | 27.5 | 118 | 53 | 45 | 67 | 67 | 77 |
| 40 | 142 | 49 | 93 | 27.5 | 27.5 | 118 | 53 | 50 | 68.5 | 67 | 80.5 |
| 50 | 150 | 57 | 93 | 27.5 | 27.5 | 120 | 51 | 62 | 72 | 67 | 89 |
| 63 | 153 | 57 | 96 | 27.5 | 27.5 | 135.5 | 54.5 | 75 | 77.5 | 69.5 | 96.5 |
| 80 | 182 | 75 | 107 | 33 | 33 | 137 | 53 | 94 | 86.5 | 69.5 | 106.5 |
| 100 | 188 | 75 | 113 | 33 | 33 | 135.5 | 54.5 | 112 | 96 | 69.5 | 115 |
| Bore size\Item | C | CB | D | DA | E | EA | F | FA | H | M | MA |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 32 | 89 | 67 | 12 | 32 | M10X1.25 | 22 | 17 | 6 | 10 | 28 | 15 |
| 40 | 94 | 72 | 16 | 34 | M12X1.25 | 24 | 17 | 7 | 13 | 32 | 15 |
| 50 | 106 | 84 | 20 | 42 | M16X1.5 | 32 | 23 | 8 | 17 | 38 | 15 |
| 63 | 124 | 97 | 20 | 42 | M16X1.5 | 32 | 23 | 8 | 17 | 38 | 15 |
| 80 | 143 | 116 | 25 | 54 | M20X1.5 | 40 | 26 | 10 | 22 | 47 | 21 |
| 100 | 161 | 134 | 25 | 54 | M20X1.5 | 40 | 26 | 10 | 22 | 47 | 21 |
| Bore size\Item | valve's type | P | Q | K | KA | KB |
|---|---|---|---|---|---|---|
| 32 | 4M210-06 | 1/8" | 1/8" | M6X1 | 16 | 33 |
| 32 | 4M210-08 | 1/4" | 1/8" | M6X1 | 16 | 33 |
| 40 | 4M210-06 | 1/8" | 1/8" | M6X1 | 16 | 37 |
| 40 | 4M210-08 | 1/4" | 1/8" | M6X1 | 16 | 37 |
| 50 | 4M210-06 | 1/8" | 1/8" | M6X1 | 16 | 47 |
| 50 | 4M210-08 | 1/4" | 1/8" | M6X1 | 16 | 47 |
| 63 | 4M310-08 | 1/4" | 1/4" | M8X1.25 | 16 | 56 |
| 63 | 4M310-10 | 3/8" | 1/4" | M8X1.25 | 16 | 56 |
| 80 | 4M310-08 | 1/4" | 1/4" | M10X1.5 | 18 | 70 |
| 80 | 4M310-10 | 3/8" | 1/4" | M10X1.5 | 18 | 70 |
| 100 | 4M310-08 | 1/4" | 1/4" | M10X1.5 | 18 | 84 |
| 100 | 4M310-10 | 3/8" | 1/4" | M10X1.5 | 18 | 84 |
Remark: The dimensions of magnet type cylinder are the same as non-magnet type cylinder.
How to use
- Options for piston rod to retract or extend when solenoid coil is energized.
- Default factory setting will be piston rod to retract when energized (see Drawing one). Should you require piston rod to extend when energized, reposition the solenoid valve as shown in Drawing two.
Attention: Ensure that the seals between the mounting block & valve are placed correctly when repositioning the valve.
SAU Series——Accessories
List for ordering code of accessories
| Accessories | Bore size | LB | FA/FB | CA | CB | Knuckle | Sensor switch | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| I: I Knuckle | Y: Y Knuckle | F: F Knuckle | U: U Knuckle | CMSG | DMSG | EMSG | ||||||
| Mounting accessories | 32 | F-SC32LB | F-SC32FA | F-SC32CA | F-SC32CB | F-M10X125I | F-M10X125Y | F-M10X125F | F-M10X125U | CMSG | DMSG | EMSG |
| 40 | F-SC40LB | F-SC40FA | F-SC40CA | F-SC40CB | F-M12X125I | F-M12X125Y | F-M12X125F | F-M12X125U | CMSG | DMSG | EMSG | |
| 50 | F-SC50LB | F-SC50FA | F-SC50CA | F-SC50CB | F-M16X150I | F-M16X150Y | F-M16X150F | F-M16X150U | CMSG | DMSG | EMSG | |
| 63 | F-SC63LB | F-SC63FA | F-SC63CA | F-SC63CB | F-M16X150I | F-M16X150Y | F-M16X150F | F-M16X150U | CMSG | DMSG | EMSG | |
| 80 | F-SC80LB | F-SC80FA | F-SC80CA | F-SC80CB | F-M20X150I | F-M20X150Y | F-M20X150F | F-M20X150U | CMSG | DMSG | EMSG | |
| 100 | F-SC100LB | F-SC100FA | F-SC100CA | F-SC100CB | F-M20X150I | F-M20X150Y | F-M20X150F | F-M20X150U | CMSG | DMSG | EMSG | |
Accessory selection
| Accessories/Cylinder model | Mounting accessories | Knuckle | Sensor switch | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LB | FA | FB | CA | CB | I | Y | U | F | CMSG | DMSG | EMSG | ||
| SAU | Standard | ● | ● | ● | ● | ● | ● | ● | ● | ● | × | × | × |
| With magnet | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | |
| SAUF | Standard | ● | ● | ● | ● | × | × | ||||||
| With magnet | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||
| SAUD | Standard | ● | ● | × | ● | ● | ● | × | × | × | |||
| With magnet | ● | ● | × | × | ● | ● | ● | ● | ● | ||||
| SAUJ | Standard | ● | ● | × | × | ● | ● | ● | ● | × | |||
| With magnet | ● | ● | × | × | ● | ● | ● | ● | ● | ● | ● | ||
[Note1] Please refer to P358~361 for knuckle detail.
Material of accessories
| Accessories | Bore size | LB | FA | FB | CA | CB | I | Y | F | U |
|---|---|---|---|---|---|---|---|---|---|---|
| Material | 32~100 | □ | ● | ◇ | ◇ | □ | □ | □ | □ | |
| ● - Aluminum alloy, ◇ - Cast steel, □ - Carbon steel | ||||||||||
Dimensions
The accessories are the same as SC series's accessories, please refer to P41~44 for details.
