Airtac 4V100 Solenoid Valve 4V110-06-B
The AirTAC Airtac 4V100 Solenoid Valve 4V110-06-B is a genuine 5/2-way single solenoid (spring return) solenoid valve with B ports and an effective area of 10.2 mm² (Cv 0.6). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port sizeB
- Effective area10.2 mm²
- Flow (Cv)0.6
- Series4V100
About the Airtac 4V100 Solenoid Valve 4V110-06-B
The 4V110-06B is a direct-acting 5/2-way solenoid valve from the AirTAC 4V100 series, configured with a DC24V coil and standard terminal-box electrical entry. It directs compressed air to one side of a double-acting cylinder while exhausting the other, and its single-solenoid design means the spool is spring-returned—the valve shifts only while the coil is energized and automatically resets when power is removed.
With an effective area of 10.2 mm² (Cv 0.6) and a response time of 0.05 seconds or less, this 1/8-inch PT-ported valve suits small-bore cylinders approximately Ø16–32 mm. The DC24V coil draws just 2.8 W, and the aluminum-alloy body weighs 120 g. It carries IP65 protection and can be mounted individually or on a shared manifold base.
Airtac 4V100 Solenoid Valve 4V110-06-B Technical Specifications
| Model | Airtac 4V100 Solenoid Valve 4V110-06-B |
|---|---|
| Series | 4V100 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | B |
| Exhaust port | B |
| Effective area (Cv) | 10.2 mm² (Cv 0.6) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 5 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 120 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 10.2 mm² |
|---|---|
| Flow coefficient | Cv 0.6 |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V100 Solenoid Valve 4V110-06-B
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 1 | Body size (4V100) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -B | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V100 Solenoid Valve 4V110-06-B Is Used
Small Clamp Actuation
Drives a double-acting pneumatic clamp on a benchtop fixture. Spring-return action ensures the clamp releases automatically when the DC24V signal is cut, providing a predictable default state for operator safety.
Pick-and-Place Grippers
Controls a miniature parallel gripper on a small assembly cell. The 0.6 Cv flow is well-matched to the low air consumption of a gripper, and the ≤0.05 s response keeps cycle times tight.
Lab Automation Sorting
Directs a double-acting slide unit that diverts vials on a laboratory sample line. The 2.8 W DC coil runs cool in continuous-duty sorting, and the IP65 rating handles occasional wash-down mist.
Is the Airtac 4V100 Solenoid Valve 4V110-06-B the Right Valve?
Choose the 4V110-06B when your application needs a compact 5/2 valve that defaults to a known safe position on power loss. If your cylinder is larger than Ø32 mm or you need faster cycling, consider stepping up to the 4V200 body (Cv 1.0) for greater flow capacity. For a valve that holds its last position without continuous power, the double-solenoid 4V120 is the direct alternative.
When replacing an existing valve, match five points: body size (4V100), function (single 5/2), port and thread (1/8-inch PT), coil voltage (DC24V), and electrical entry (terminal box). This model’s terminal-box wiring keeps the DIN connector accessible, and the valve can be banked on a 4V100 manifold if you are controlling multiple actuators from a single supply.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V100 Solenoid Valve 4V110-06-B FAQ
With a 10.2 mm² effective area (Cv 0.6), it suits double-acting cylinders roughly Ø16–32 mm in typical cycling applications. For larger bores or very high-speed cycling, moving to a 4V200-series valve (Cv 1.0) will give you the extra flow you need.
No—the 4V110 is a single-solenoid, spring-return valve. It requires a constant DC24V signal to hold the shifted position. When power is removed, the internal spring pushes the spool back to its home position, exhausting the previously pressurized cylinder port.
