AirTAC MGC63 Cushioned Mini Cylinder, 63 mm Bore
Every AirTAC MGC63 configuration on one page: 20 stock order codes with strokes from 25 to 800 mm and 1 mounting, from $82.86. Pick a stroke, mounting and version to see the exact order code and price.
Basic (no mounting)
This combination is not a stock order code. Request a quote and we will confirm availability and price.
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC MGC63
The AirTAC MGC63 is a double-acting stainless-steel mini cylinder with adjustable cushions with a 63 mm bore and a 20 mm piston rod. At 0.5 MPa it pushes 1559 N and pulls 1402 N; at 0.7 MPa that rises to 2182 N push and 1962 N pull. Force depends on bore and pressure only, so every stroke on this page gives the same output.
All MGC63 versions share 1/4" air ports, an M18×1.5 rod thread and adjustable air cushions at both ends. The cylinder runs on filtered air between 0.15 and 1.0 MPa (proof 1.5 MPa), from -20 to +70 °C, at 30 to 800 mm/s. This page lists 20 stock order codes with strokes from 25 to 800 mm; the catalog maximum stroke is 500 mm, and the longer codes are non-standard strokes we already supply.
MGC63 Technical Specifications
| Bore size | Ø63 mm |
|---|---|
| Stock strokes | 25 – 800 mm |
| Catalog maximum stroke | 500 mm (longer on request) |
| Acting type | Double acting |
| Port size | 1/4" (PT standard) |
| Piston rod / rod thread | Ø20 mm / M18×1.5 |
| Fluid | Air (filtered by 40 µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable air cushion |
Source: AirTAC Products Catalog 2026A (PDF01-P0449), MG (MGC cushioned) series ordering code and specifications.
Theoretical output force (Ø63 mm)
| Pressure | Push | Pull |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | 1962 N |
Push = pressure × bore area; pull subtracts the Ø20 mm rod area. Usable force is lower because of friction and back-pressure.
How the MGC63 Order Code Is Built
| MGC63 | Series and bore (63 mm) |
|---|---|
| X100 | Stroke in mm |
| S | Built-in magnet for position sensors (blank = none) |
| CB / FA / LB / SDB | Mounting: CB double clevis; FA flange; LB foot bracket; SDB pivot bracket (blank = none) |
| G / T | Port thread: G = G (BSPP), T = NPT, blank = PT |
All AirTAC MGC63 Order Codes (20)
Each order code links to its own datasheet page. Use Select to load it into the configurator above.
| Order code | Stroke (mm) | Mounting | Magnet · Thread | Price | Select |
|---|---|---|---|---|---|
| MGC63X25S | 25 mm | Basic (no mounting) | S · PT | $83.30 | |
| MGC63X50 | 50 mm | Basic (no mounting) | - · PT | $82.86 | |
| MGC63X50S | 50 mm | Basic (no mounting) | S · PT | $86.35 | |
| MGC63X60 | 60 mm | Basic (no mounting) | - · PT | $86.15 | |
| MGC63X75 | 75 mm | Basic (no mounting) | - · PT | $86.15 | |
| MGC63X75S | 75 mm | Basic (no mounting) | S · PT | $89.64 | |
| MGC63X90S | 90 mm | Basic (no mounting) | S · PT | $92.69 | |
| MGC63X250 | 250 mm | Basic (no mounting) | - · PT | $108.58 | |
| MGC63X250S | 250 mm | Basic (no mounting) | S · PT | $112.06 | |
| MGC63X300 | 300 mm | Basic (no mounting) | - · PT | $114.92 | |
| MGC63X300S | 300 mm | Basic (no mounting) | S · PT | $118.41 | |
| MGC63X350 | 350 mm | Basic (no mounting) | - · PT | $121.02 | |
| MGC63X350S | 350 mm | Basic (no mounting) | S · PT | $124.51 | |
| MGC63X400 | 400 mm | Basic (no mounting) | - · PT | $127.12 | |
| MGC63X400S | 400 mm | Basic (no mounting) | S · PT | $130.61 | |
| MGC63X450 | 450 mm | Basic (no mounting) | - · PT | $133.23 | |
| MGC63X450S | 450 mm | Basic (no mounting) | S · PT | $136.72 | |
| MGC63X500 | 500 mm | Basic (no mounting) | - · PT | $139.33 | |
| MGC63X500S | 500 mm | Basic (no mounting) | S · PT | $142.81 | |
| MGC63X800 | 800 mm | Basic (no mounting) | - · PT | $186.40 |
Need a combination that is not listed? Request a quote.
Where the MGC63 Is Used
General automation
About 1559 N at 0.5 MPa covers most pushing, lifting and indexing tasks.
Clamping fixtures
Rigid mountings hold the cylinder for clamps and presses.
Doors, gates and levers
Pivoting covers and brackets drive mechanisms that swing.
Choosing the Right MGC63 Configuration
Start with the stroke. Pick the exact travel your machine needs; a longer stroke adds length, weight and air consumption without adding force. If your length is not listed, request a quote and we will confirm whether it can be built.
Then choose the mounting. Basic (no code) uses the cylinder's own mounting holes. Foot and flange mountings hold the cylinder rigid for straight-line loads; clevis and trunnion mountings let it pivot when the load moves in an arc.
Finally pick the version: S adds a magnet for position sensors.
AirTAC MGC63 FAQ
No. Every MGC63 gives about 1559 N push and 1402 N pull at 0.5 MPa, whatever the stroke.
1/4" ports, PT thread as standard.
Basic mounting only. Pick a pivoting cover or bracket when the load moves in an arc, a rigid one for straight-line loads.
Usually yes. Request a quote with the stroke, mounting and version and we will confirm whether it can be built, plus price and lead time.
0.15 to 1.0 MPa operating pressure (proof 1.5 MPa) and -20 to +70 °C on filtered air.
No. You can order a single MGC63. Orders are processed and handed to the carrier within 3-5 business days.
Buying the MGC63 from AirtacDistr
Genuine AirTAC parts
Every order code on this page is the AirTAC factory part number. Specifications follow the AirTAC Products Catalog 2026A. About us
Ready in 3-5 business days
That is our time to process the order and hand it to the carrier. No minimum order: a single piece can be ordered.
14-day returns, 1-year warranty
Return within 14 days of delivery; the buyer pays return shipping. The warranty covers defects not caused by misuse. Return policy
Engineering help
Send your application details and we will confirm the right order code, usually within 7-8 hours. Ask us
Page data checked against the live catalog on 2026-10-28.
