AirTAC ACQJ Series · Ø63 mm stroke-adjustable compact (ultra-thin) cylinder
AirTAC ACQJ63 Adjustable-Stroke Cylinder, 63 mm Bore
Every AirTAC ACQJ63 configuration on one page: 445 stock order codes with strokes from 5 to 300 mm, 1 adjustment values (10-100 mm), 1 mounting style and magnet, seal and thread versions, from $52.33. Pick a stroke, adjustment, mounting and version to see the exact order code and price.
This combination is not a stock order code. Request a quote and we will confirm availability and price.
$80.25
$87.75Save 8%
Request a Quote
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC ACQJ63
The AirTAC ACQJ63 is a double-acting stroke-adjustable compact (ultra-thin) cylinder with a 63 mm bore and a 20 mm piston rod. At 0.5 MPa it pushes 1559 N and pulls 1402 N; at 0.7 MPa that rises to 2182 N push and 1962 N pull. A rear stroke-adjustment screw lets you shorten the travel by up to the adjustment amount in the code (10-100 mm across the codes on this page). Force depends on bore and pressure only, so every stroke on this page gives the same output.
All ACQJ63 versions share 1/4" air ports, an M10×1.5 female rod thread (B versions have a M18×1.5 male rod end) and rubber bumpers at both ends. The cylinder runs on filtered air between 0.15 and 1.0 MPa (proof 1.5 MPa), from -20 to +70 °C, at 30 to 500 mm/s. This page lists 445 stock order codes with strokes from 5 to 300 mm; catalog standard strokes run up to 100 mm, and the longer codes are non-standard strokes we already supply.
ACQJ63 Technical Specifications
| Bore size | Ø63 mm |
|---|---|
| Stock strokes | 5 – 300 mm |
| Catalog standard stroke | up to 100 mm (longer on request) |
| Acting type | Double acting |
| Port size | 1/4" (PT standard) |
| Piston rod / rod thread | Ø20 mm / M10×1.5 female; M18×1.5 male (B) |
| Fluid | Air (filtered by 40 µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Rubber bumper at both ends |
Source: AirTAC Products Catalog 2026A, ACQ series (ACQJ adjustable-stroke version). B = male rod end; blank = female rod end.
Theoretical output force (Ø63 mm)
| Pressure | Push | Pull |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | 1962 N |
Push = pressure × bore area; pull subtracts the Ø20 mm rod area. Usable force is lower because of friction and back-pressure.
How the ACQJ63 Order Code Is Built
| ACQJ63 | Series and bore (63 mm) |
|---|---|
| X100 | Stroke in mm |
| -10 | Stroke adjustment in mm (10, 20, 30, 40, 50, 75, 100) |
| S | Built-in magnet for position sensors (blank = none) |
| B | Male threaded rod end (blank = female) |
| - | Mounting: basic only |
| H / N | Seal: H = FKM, N = NBR (blank = standard seal) |
| G / T | Port thread: G = G (BSPP), T = NPT, blank = PT |
All AirTAC ACQJ63 Order Codes (445)
Each order code links to its own datasheet page. Use Select to load it into the configurator above.
| Order code | Stroke (mm) | Adjust (mm) | Mounting · Magnet · Rod end · Seal · Thread | Price | Select |
|---|---|---|---|---|---|
| ACQJ63X5-10 | 5 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $52.33 | |
| ACQJ63X5-10B | 5 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $52.33 | |
| ACQJ63X5-10S | 5 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $62.57 | |
| ACQJ63X5-10SB | 5 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $62.57 | |
| ACQJ63X10-10 | 10 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $54.66 | |
| ACQJ63X10-10B | 10 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $54.66 | |
| ACQJ63X10-10S | 10 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $64.89 | |
| ACQJ63X10-10SB | 10 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $64.89 | |
| ACQJ63X15-10 | 15 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $56.98 | |
| ACQJ63X15-10B | 15 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $56.98 | |
| ACQJ63X15-10S | 15 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $66.96 | |
| ACQJ63X15-10SB | 15 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $66.96 | |
| ACQJ63X15-20 | 15 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $56.98 | |
| ACQJ63X15-20B | 15 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $56.98 | |
| ACQJ63X15-20S | 15 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $66.96 | |
| ACQJ63X15-20SB | 15 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $66.96 | |
| ACQJ63X20-10 | 20 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $59.05 | |
| ACQJ63X20-10B | 20 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $59.05 | |
| ACQJ63X20-10S | 20 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $69.29 | |
| ACQJ63X20-10SB | 20 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $69.29 | |
| ACQJ63X20-20 | 20 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $59.05 | |
| ACQJ63X20-20B | 20 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $59.05 | |
| ACQJ63X20-20BH | 20 mm | 20 mm | Basic (no mounting) · - · male rod (B) · FKM · PT | $72.08 | |
| ACQJ63X20-20S | 20 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $69.29 | |
| ACQJ63X20-20SB | 20 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $69.29 | |
| ACQJ63X25-10 | 25 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $61.63 | |
| ACQJ63X25-10B | 25 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $61.63 | |
| ACQJ63X25-10S | 25 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $71.61 | |
| ACQJ63X25-10SB | 25 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $71.61 | |
| ACQJ63X25-20 | 25 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $61.63 | |
| ACQJ63X25-20B | 25 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $61.63 | |
| ACQJ63X25-20S | 25 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $71.61 | |
| ACQJ63X25-20SB | 25 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $71.61 | |
| ACQJ63X25-30 | 25 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $61.63 | |
| ACQJ63X25-30B | 25 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $61.63 | |
| ACQJ63X25-30S | 25 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $71.61 | |
| ACQJ63X25-30SB | 25 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $71.61 | |
| ACQJ63X30-10 | 30 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $63.50 | |
| ACQJ63X30-10B | 30 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $63.50 | |
| ACQJ63X30-10S | 30 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $73.94 | |
| ACQJ63X30-10SB | 30 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $73.94 | |
| ACQJ63X30-20 | 30 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $63.50 | |
| ACQJ63X30-20B | 30 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $63.50 | |
| ACQJ63X30-20S | 30 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $73.94 | |
| ACQJ63X30-20SH | 30 mm | 20 mm | Basic (no mounting) · S · female rod · FKM · PT | $86.97 | |
| ACQJ63X30-20SB | 30 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $73.94 | |
| ACQJ63X30-30 | 30 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $63.50 | |
| ACQJ63X30-30B | 30 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $63.50 | |
| ACQJ63X30-30S | 30 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $73.94 | |
| ACQJ63X30-30SB | 30 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $73.94 | |
| ACQJ63X35-10 | 35 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $66.03 | |
| ACQJ63X35-10B | 35 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $66.03 | |
| ACQJ63X35-10S | 35 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $76.53 | |
| ACQJ63X35-10SB | 35 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $76.53 | |
| ACQJ63X35-20 | 35 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $66.03 | |
| ACQJ63X35-20B | 35 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $66.03 | |
| ACQJ63X35-20S | 35 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $76.53 | |
| ACQJ63X35-20SB | 35 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $76.53 | |
| ACQJ63X35-30 | 35 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $66.03 | |
| ACQJ63X35-30B | 35 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $66.03 | |
| ACQJ63X35-30S | 35 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $76.53 | |
| ACQJ63X35-30SB | 35 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $76.53 | |
| ACQJ63X35-40 | 35 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $66.03 | |
| ACQJ63X35-40B | 35 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $66.03 | |
| ACQJ63X35-40S | 35 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $76.53 | |
| ACQJ63X35-40SB | 35 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $76.53 | |
| ACQJ63X40-10 | 40 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $67.89 | |
| ACQJ63X40-10B | 40 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $67.89 | |
| ACQJ63X40-10S | 40 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $78.39 | |
| ACQJ63X40-10SB | 40 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $78.39 | |
| ACQJ63X40-20 | 40 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $67.89 | |
| ACQJ63X40-20B | 40 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $67.89 | |
| ACQJ63X40-20S | 40 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $78.39 | |
| ACQJ63X40-20SB | 40 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $78.39 | |
| ACQJ63X40-30 | 40 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $67.89 | |
| ACQJ63X40-30B | 40 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $67.89 | |
| ACQJ63X40-30S | 40 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $78.39 | |
| ACQJ63X40-30SB | 40 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $78.39 | |
| ACQJ63X40-40 | 40 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $67.89 | |
| ACQJ63X40-40B | 40 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $67.89 | |
| ACQJ63X40-40S | 40 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $78.39 | |
| ACQJ63X40-40SB | 40 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $78.39 | |
| ACQJ63X45-10 | 45 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $70.22 | |
| ACQJ63X45-10B | 45 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $70.22 | |
| ACQJ63X45-10S | 45 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $80.25 | |
| ACQJ63X45-10SB | 45 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $80.25 | |
| ACQJ63X45-20 | 45 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $70.22 | |
| ACQJ63X45-20B | 45 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $70.22 | |
| ACQJ63X45-20S | 45 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $80.25 | |
| ACQJ63X45-20SB | 45 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $80.25 | |
| ACQJ63X45-30 | 45 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $70.22 | |
| ACQJ63X45-30B | 45 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $70.22 | |
| ACQJ63X45-30S | 45 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $80.25 | |
| ACQJ63X45-30SB | 45 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $80.25 | |
| ACQJ63X45-40 | 45 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $70.22 | |
| ACQJ63X45-40B | 45 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $70.22 | |
| ACQJ63X45-40S | 45 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $80.25 | |
| ACQJ63X45-40SB | 45 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $80.25 | |
| ACQJ63X45-50 | 45 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $70.22 | |
| ACQJ63X45-50B | 45 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $70.22 | |
| ACQJ63X45-50S | 45 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $80.25 | |
| ACQJ63X45-50SB | 45 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $80.25 | |
| ACQJ63X50-10 | 50 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $72.55 | |
| ACQJ63X50-10B | 50 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $72.55 | |
| ACQJ63X50-10S | 50 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $83.04 | |
| ACQJ63X50-10SB | 50 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $83.04 | |
| ACQJ63X50-20 | 50 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $72.55 | |
| ACQJ63X50-20B | 50 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $72.55 | |
| ACQJ63X50-20S | 50 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $83.04 | |
| ACQJ63X50-20SB | 50 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $83.04 | |
| ACQJ63X50-30 | 50 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $72.55 | |
| ACQJ63X50-30B | 50 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $72.55 | |
| ACQJ63X50-30S | 50 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $83.04 | |
| ACQJ63X50-30SB | 50 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $83.04 | |
| ACQJ63X50-40 | 50 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $72.55 | |
| ACQJ63X50-40B | 50 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $72.55 | |
| ACQJ63X50-40S | 50 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $83.04 | |
| ACQJ63X50-40SB | 50 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $83.04 | |
| ACQJ63X50-50 | 50 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $72.55 | |
| ACQJ63X50-50B | 50 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $72.55 | |
| ACQJ63X50-50S | 50 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $83.04 | |
| ACQJ63X50-50SB | 50 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $83.04 | |
| ACQJ63X60-10 | 60 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-10B | 60 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-10S | 60 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X60-10SB | 60 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $87.43 | |
| ACQJ63X60-20 | 60 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-20B | 60 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-20S | 60 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X60-20SB | 60 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $87.43 | |
| ACQJ63X60-30 | 60 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-30B | 60 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-30S | 60 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X60-30SB | 60 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $87.43 | |
| ACQJ63X60-40 | 60 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-40B | 60 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-40S | 60 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X60-40SB | 60 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $87.43 | |
| ACQJ63X60-50 | 60 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-50B | 60 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-50S | 60 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X60-50SB | 60 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $87.43 | |
| ACQJ63X60-75 | 60 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $77.45 | |
| ACQJ63X60-75B | 60 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $77.45 | |
| ACQJ63X60-75S | 60 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $87.43 | |
| ACQJ63X70-10 | 70 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-10B | 70 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-10S | 70 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-10SB | 70 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X70-20 | 70 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-20B | 70 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-20S | 70 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-20SB | 70 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X70-30 | 70 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-30B | 70 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-30S | 70 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-30SB | 70 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X70-40 | 70 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-40B | 70 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-40S | 70 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-40SB | 70 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X70-50 | 70 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-50B | 70 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-50S | 70 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-50SB | 70 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X70-75 | 70 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $81.85 | |
| ACQJ63X70-75B | 70 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $81.85 | |
| ACQJ63X70-75S | 70 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $91.88 | |
| ACQJ63X70-75SB | 70 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $91.88 | |
| ACQJ63X75-10 | 75 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-10B | 75 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-10S | 75 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-10SB | 75 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X75-20 | 75 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-20B | 75 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-20S | 75 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-20SB | 75 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X75-30 | 75 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-30B | 75 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-30S | 75 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-30SB | 75 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X75-40 | 75 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-40B | 75 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-40S | 75 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-40SB | 75 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X75-50 | 75 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-50B | 75 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-50S | 75 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-50SB | 75 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X75-75 | 75 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $83.97 | |
| ACQJ63X75-75B | 75 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $83.97 | |
| ACQJ63X75-75S | 75 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $94.41 | |
| ACQJ63X75-75SB | 75 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $94.41 | |
| ACQJ63X80-10 | 80 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-10B | 80 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-10S | 80 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-10SB | 80 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-20 | 80 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-20B | 80 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-20S | 80 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-20SB | 80 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-30 | 80 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-30B | 80 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-30S | 80 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-30SB | 80 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-40 | 80 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-40B | 80 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-40S | 80 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-40SB | 80 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-50 | 80 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-50B | 80 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-50S | 80 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-50SB | 80 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-75 | 80 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-75B | 80 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-75S | 80 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-75SB | 80 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X80-100 | 80 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $86.76 | |
| ACQJ63X80-100B | 80 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $86.76 | |
| ACQJ63X80-100S | 80 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $97.21 | |
| ACQJ63X80-100SB | 80 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $97.21 | |
| ACQJ63X90-10 | 90 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-10B | 90 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-10S | 90 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-10SB | 90 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-20 | 90 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-20B | 90 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-20S | 90 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-20SB | 90 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-30 | 90 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-30B | 90 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-30S | 90 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-30SB | 90 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-40 | 90 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-40B | 90 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-40S | 90 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-40SB | 90 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-50 | 90 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-50B | 90 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-50S | 90 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-50SB | 90 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-75 | 90 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-75B | 90 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-75S | 90 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-75SB | 90 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X90-100 | 90 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $92.81 | |
| ACQJ63X90-100B | 90 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $92.81 | |
| ACQJ63X90-100S | 90 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $103.05 | |
| ACQJ63X90-100SB | 90 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $103.05 | |
| ACQJ63X100-10 | 100 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-10B | 100 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-10S | 100 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-10SB | 100 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-20 | 100 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-20B | 100 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-20S | 100 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-20SB | 100 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-30 | 100 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-30B | 100 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-30S | 100 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-30SB | 100 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-40 | 100 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-40B | 100 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-40S | 100 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-40SB | 100 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-50 | 100 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-50B | 100 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-50S | 100 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-50SB | 100 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-75 | 100 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-75B | 100 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-75S | 100 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-75SB | 100 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X100-100 | 100 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $97.46 | |
| ACQJ63X100-100B | 100 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $97.46 | |
| ACQJ63X100-100S | 100 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $107.91 | |
| ACQJ63X100-100SB | 100 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $107.91 | |
| ACQJ63X125-10 | 125 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-10B | 125 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-10S | 125 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-10SB | 125 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-20 | 125 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-20B | 125 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-20S | 125 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-20SB | 125 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-30 | 125 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-30B | 125 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-30S | 125 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-30SB | 125 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-40 | 125 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-40B | 125 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-40S | 125 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-40SB | 125 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-50 | 125 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-50B | 125 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-50S | 125 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-50SB | 125 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-75 | 125 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-75B | 125 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-75S | 125 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-75SB | 125 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X125-100 | 125 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $122.59 | |
| ACQJ63X125-100B | 125 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $122.59 | |
| ACQJ63X125-100S | 125 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $132.57 | |
| ACQJ63X125-100SB | 125 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $132.57 | |
| ACQJ63X150-10 | 150 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-10B | 150 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-10S | 150 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-10SB | 150 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-20 | 150 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-20B | 150 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-20S | 150 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-20SB | 150 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-30 | 150 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-30B | 150 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-30S | 150 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-30SB | 150 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-40 | 150 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-40B | 150 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-40S | 150 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-40SB | 150 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-50 | 150 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-50B | 150 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-50S | 150 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-50SB | 150 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-75 | 150 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-75B | 150 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-75S | 150 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-75SB | 150 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X150-100 | 150 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $136.08 | |
| ACQJ63X150-100B | 150 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $136.08 | |
| ACQJ63X150-100S | 150 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $146.06 | |
| ACQJ63X150-100SB | 150 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $146.06 | |
| ACQJ63X175-10 | 175 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-10B | 175 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-10S | 175 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-10SB | 175 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-20 | 175 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-20B | 175 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-20S | 175 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-20SB | 175 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-30 | 175 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-30B | 175 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-30S | 175 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-30SB | 175 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-40 | 175 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-40B | 175 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-40S | 175 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-40SB | 175 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-50 | 175 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-50B | 175 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-50S | 175 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-50SB | 175 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-75 | 175 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-75B | 175 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-75S | 175 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-75SB | 175 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X175-100 | 175 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $149.58 | |
| ACQJ63X175-100B | 175 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $149.58 | |
| ACQJ63X175-100S | 175 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $159.55 | |
| ACQJ63X175-100SB | 175 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $159.55 | |
| ACQJ63X200-10 | 200 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-10B | 200 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-10S | 200 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-10SB | 200 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-20 | 200 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-20B | 200 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-20S | 200 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-20SB | 200 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-30 | 200 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-30B | 200 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-30S | 200 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-30SB | 200 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-40 | 200 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-40B | 200 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-40S | 200 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-40SB | 200 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-50 | 200 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-50B | 200 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-50S | 200 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-50SB | 200 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-75 | 200 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-75B | 200 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-75S | 200 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-75SB | 200 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X200-100 | 200 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $163.07 | |
| ACQJ63X200-100B | 200 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $163.07 | |
| ACQJ63X200-100S | 200 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $173.51 | |
| ACQJ63X200-100SB | 200 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $173.51 | |
| ACQJ63X250-10 | 250 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-10B | 250 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-10S | 250 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-10SB | 250 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-20 | 250 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-20B | 250 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-20S | 250 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-20SB | 250 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-30 | 250 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-30B | 250 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-30S | 250 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-30SB | 250 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-40 | 250 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-40B | 250 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-40S | 250 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-40SB | 250 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-50 | 250 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-50B | 250 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-50S | 250 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-50SB | 250 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-75 | 250 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-75B | 250 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-75S | 250 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-75SB | 250 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X250-100 | 250 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $197.03 | |
| ACQJ63X250-100B | 250 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $197.03 | |
| ACQJ63X250-100S | 250 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $207.48 | |
| ACQJ63X250-100SB | 250 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $207.48 | |
| ACQJ63X300-10 | 300 mm | 10 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-10B | 300 mm | 10 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-10S | 300 mm | 10 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-10SB | 300 mm | 10 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-20 | 300 mm | 20 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-20B | 300 mm | 20 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-20S | 300 mm | 20 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-20SB | 300 mm | 20 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-30 | 300 mm | 30 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-30B | 300 mm | 30 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-30S | 300 mm | 30 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-30SB | 300 mm | 30 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-40 | 300 mm | 40 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-40B | 300 mm | 40 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-40S | 300 mm | 40 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-40SB | 300 mm | 40 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-50 | 300 mm | 50 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-50B | 300 mm | 50 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-50S | 300 mm | 50 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-50SB | 300 mm | 50 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-75 | 300 mm | 75 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-75B | 300 mm | 75 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-75S | 300 mm | 75 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-75SB | 300 mm | 75 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 | |
| ACQJ63X300-100 | 300 mm | 100 mm | Basic (no mounting) · - · female rod · std seal · PT | $224.23 | |
| ACQJ63X300-100B | 300 mm | 100 mm | Basic (no mounting) · - · male rod (B) · std seal · PT | $224.23 | |
| ACQJ63X300-100S | 300 mm | 100 mm | Basic (no mounting) · S · female rod · std seal · PT | $234.46 | |
| ACQJ63X300-100SB | 300 mm | 100 mm | Basic (no mounting) · S · male rod (B) · std seal · PT | $234.46 |
Need a combination that is not listed? Request a quote.
Where the ACQJ63 Is Used
General automation
About 1559 N at 0.5 MPa covers most pushing, lifting and indexing tasks.
Clamping fixtures
Foot or flange mounting holds the cylinder rigid for clamps.
Doors, gates and levers
Clevis and trunnion versions drive mechanisms that swing.
Choosing the Right ACQJ63 Configuration
Start with the stroke. Pick the exact travel your machine needs; a longer stroke adds length, weight and air consumption without adding force. If your length is not listed, request a quote and we will confirm whether it can be built.
Then the stroke adjustment (10-100 mm): pick the amount by which you need to trim the stroke on the machine. The cylinder can be set anywhere between full stroke and full stroke minus that amount.
Then choose the mounting. Basic (no code) uses the cylinder's own mounting holes. Foot and flange mountings hold the cylinder rigid for straight-line loads; clevis and trunnion mountings let it pivot when the load moves in an arc.
Finally pick the version: S adds a magnet for position sensors; the standard seal suits general automation; B gives a male threaded rod end instead of the standard female thread; H (FKM) is for higher temperatures or oil-contaminated air.
AirTAC ACQJ63 FAQ
No. Every ACQJ63 gives about 1559 N push and 1402 N pull at 0.5 MPa, whatever the stroke.
The number after the dash is the adjustable range in mm. An ACQJ63X100-50, for example, can be set to any stroke between 50 and 100 mm with the rear adjusting screw.
1/4" ports, PT thread as standard.
Basic mounting. Use foot or flange for straight-line loads, clevis or trunnion when the cylinder must pivot.
Usually yes. Request a quote with the stroke, mounting and version and we will confirm whether it can be built, plus price and lead time.
0.15 to 1.0 MPa operating pressure (proof 1.5 MPa) and -20 to +70 °C on filtered air.
No. You can order a single ACQJ63. Orders are processed and handed to the carrier within 3-5 business days.
Buying the ACQJ63 from AirtacDistr
Genuine AirTAC parts
Every order code on this page is the AirTAC factory part number. Specifications follow the AirTAC Products Catalog 2026A. About us
Ready in 3-5 business days
That is our time to process the order and hand it to the carrier. No minimum order: a single piece can be ordered.
14-day returns, 1-year warranty
Return within 14 days of delivery; the buyer pays return shipping. The warranty covers defects not caused by misuse. Return policy
Engineering help
Send your application details and we will confirm the right order code, usually within 7-8 hours. Ask us
Page data checked against the live catalog on 2026-09-28.
Request a Quote for the ACQJ63
Send the order code, quantity and destination. We confirm price, stock and lead time, usually within 7-8 hours.
Thank you. We received your request for ACQJ63X45-10S and will confirm price, stock and lead time — usually within 7-8 hours.
